High Quality Air Cooled Diesel Engine

High Quality Air Cooled Diesel Engine thumbnail-1
High Quality Air Cooled Diesel Engine photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, AGRICULTURE
Fuel:
Diesel
Contact Supplier Request Quote Chat Now
Basant Products India
Payment & Shipping
Payment Methods:
Port of Shipment:
mumbai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Other, AGRICULTURE
Fuel Diesel
Stroke 4 Stroke
Cylinder Single Cylinder
Cold Style Other, Air-cooled
Start Electric Start
Place of Origin Uttar Pradesh, India
Brand Name Vidhata
Model Number VHA-2

Specifications

1 H.P 10
2 Cooling - Air
3 Type - kirloskar type
4 Pump - 4x4 Centrifugal Type
5 Mouned on MS base frame





BRIEF SPECIFICATIONS



TYPE



Vertical, Single / Double Cylinder, Water Cooled, Totally Enclosed, Compression Ignition, Four Stroke, Cold Start, Diesel Engine.







COMBUSTION CHAMBER



Direct injection in open type combustion chamber provided in an aluminium alloy piston with long stem multihole nozzle resultsinto low fuel consumption and easy starting.







FUEL SYSTEM



High Speed diesel is supplied to the fuel pump by gravity feed through an efficient replacable paper element type main filter. Industrial type double bowl heavy duty type filter BOSH make also available.







LUBRICATION



Engine’s moving parts are lubricated by force feed and partly by splash lubrication. A throwaway type bypass filter is provided for filtering the lubricating oil. Lub. Oil is supplied under constant pressure by lub. Oil pump. Centrifigal type Lub. Oil cleaner also available for long engine life.







GOVERNING



A sensible mechnanical centrifugal type governer mounted on the camshaft gear. Speed variation is controlledwithin limits to comply with class B1 governing as per IS:10001 (GENERAL PURPOSE)







COOLING



Engine is continuously cooled by flow of water. Either by Radiator mounted on engine or direct water supply. Front radiator mounted engines also available.







ROTATION



Standard rotation is clockwise looing at fly wheel. Engine with reverse rotation can also be provided on demand.







STARTING



The engine is designed for starting by hand. Electric Start Provision can also be provided against specific reauirement. Dynamo battery chargers also available.







DRIVE



Standerd power take off is from flywheel side. Power Take off from gear end at half speed can be provided on demand.







STANDERD ACCESSORIES



Starting handle, Exhaust Silencer, Air Cleaner, Spanner Set & Screw Driver.







OPTIONAL ACCESSORIES



Drum Pulley, Variable speed Lever, Fly wheel Guard, Engine lift hook.







POLLUTION CONTROL DEVICE



Single Element Catalytic Converter for control of NOx, CO, THC & HAPs.







SOUND & VIBRATION CONTROL DEVICE



We offer Canopy, Industrial type Air cleaner & Silencer, Round Duct Expansion Joints, Anti Vibration Mounts etc.







SOUND & VIBRATION CONTROL DEVICE



We offer Canopy, Industrial type Air cleaner & Silencer, Round Duct Expansion Joints, Anti Vibration Mounts etc.







USE



These water pump set are used to lift water from deep well, lake, ponds, river etc for irrigation these type of pump set are used widely by thousands of Asian & African farmers as the pump and engine design are simple so they are long life and easy reparable and long lasting performance. Main feature was low RPM 1500 so that minimum wear & tear of spares. Engines (Hand Start or electric start optional) between 4 and 28 H.P Direct Coupled to Water Pumps, either Centrifugal or Self Priming Sets should be built on steel base. Stationery on the steel base, and Portable using Rubber Wheels (Coasters), and handle in order to move the set from one place to another. The Engines of those sets are cooled automatically from the pumps, as the pumps sends the cold water through a hose to the Cylinder head as an intake. The outlet side for warm water is the hopper cover. This way the engine is kept cool during the operation. The outlet water is not wasted, because it is used for irrigation also.







STANDARD PARTS



Air Cleaner, Silencer, Wrench Set, Screw Driver, Starting Handle, One Bag, Oil Can , Instruction Manual.







APPLICATION



These Pump Sets can be used in Agriculture ,Irrigation, Mining, Forestry Culture, Fishing and other purposes.







ADDITIONAL PRODUCT INFORMATION







User Application Sector Power, Construction and Earthmoving, Agriculture, Industry



User Sub Sector Power generation, Infrastructure, Large community irrigation schemes, Farm irrigation, Harvesting, Food processing



Industry Sector Diesel power, Construction Equipments, Aquaculture



Application Areas Prime movers, Prime Mover, Pumping systems, Flood irrigation, Agricultural implements, Fluid handling
