Magnesium alloy billet slab rod bar
- 500 Ton / Tons per Month
- Ningbo
- T/T L/C D/P D/A
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | YUXI | Model Number: | AZ31B, ZK60A, AZ61A, AZ80A, M1C |
Application: | carving, aeroplane, automobile, 3 C products | Shape: | Rod,Bar, Billet,Slab | Material: | Magnesium |
Dimensions: | Customzied | Chemical Composition: | MgMnAl; MgMnZn |
Product Description
AZ31B, ZK60A, AZ61A, AZ80A, M1C Magnesium Alloy Billet/ Slab/ Rod/Bar
Direct chill cast billet is manufactured by YUXI as the starting material for other magnesium products, such as sheet, plate, forgings and extrusions. However, it has been frequently found that the cast billet is suitable for machining into prototypes, thus avoiding expensive tooling, and in some cases for production where the size of the finished items is outside economic casting or extrusion dimension or minimum economic production.
Cast billet is supplied to clients on the compositional and homogenized condition. The Chemical Composition is as per AZ31B, AZ61A, AZ80A and ZK60A. Inspection standards for billet will be by agreement. Ultrasonic Inspection as per AMS-STD-2154 Class A. Temporary corrosion preventative surface treatments can be applied by agreement.
CONTINUOUS CAST MACHINING MAGNESIUM ALLOY SLAB
YUXI supplies direct chill continuous cast machining slab for manufacturer of parts which are larger than possible by conventional production methods, the shape of slab is rectangular, with two opposing faced and edges (if required) machined, and then sawn to ordered size. The alloy for machining stock is AZ31B per the chemical composition requirements of ASTM B90/B90M-07.
Specification
Max dimension of cast rod: dia 600*4500mm
Max dimension of cast slab: 340*960*2000mm
Max thickness: 340mm(after machining)
Max width:960mm (after machining)
Max length:2000mm (after sawing)
Chemical Composition
AZ31B | ASTM B 107/B 107M | ||||||||
Elements | Al | Zn | Mn | Si | Fe | Cu | Ni | Ca | Others,total |
Min% | 2.50 | 0.60 | 0.20 | ||||||
Max% | 3.50 | 1.40 | 1.00 | 0.10 | 0.005 | 0.05 | 0.005 | 0.04 | 0.3 |
ZK60A | ASTM B 107/B 107M | ||
Elements | Zn | Zr | Others,total |
Min% | 4.8 | 0.45 | |
Max% | 6.2 | 0.3 |
AZ61A | ASTM B 107/B 107M | |||||||
Elements | Al | Zn | Mn | Si | Fe | Cu | Ni | Others,total |
Min% | 5.80 | 0.45 | 0.15 | |||||
Max% | 7.20 | 1.50 | 0.50 | 0.10 | 0.005 | 0.05 | 0.005 | 0.3 |
AZ80A | ASTM B 107/B 107M | |||||||
Elements | Al | Zn | Mn | Si | Fe | Cu | Ni | Others,total |
Min% | 7.80 | 0.20 | 0.12 | |||||
Max% | 9.20 | 0.80 | 0.50 | 0.10 | 0.005 | 0.05 | 0.005 |
M1C | ASTM B 843 | |||||||
Elements | Al | Si | Mn | Fe | Cu | Ni | Others,each | Others,total |
Min% | 0.50 | |||||||
Max% | 0.01 | 0.05 | 1.30 | 0.03 | 0.02 | 0.001 | 0.05 | 0.3 |
Application
At present, the application on the spare parts on automobiles can be categorized in two types.
- a. Enclosure. Clutch. Valve deck. Instrument board. Gearbox casing. Crank case. Engine front cover. Cylinder cover. Air-conditioner shell.
- b. Stand. Steering wheel. Steering bracket. Brake bracket. Seat frame. Car mirror bracket. Distribution support.
Mobile phone, personal computer: support frame and the back shell
Electronic appliance (computer, projector, television set: Mg alloy has higher heat conductivity coefficient than plastic, which is beneficial for the heat dissipation.
Hard disk drive: reading device. Electric fan: fan blade( low noise) steeling wheel and seat: lighter, absorbing the impact from strike)
List of Machinery & CNC machines
S. No. | Machine Name | Model | Quantity |
1 | Liquation furnace | RJC-135-9 | 2 |
2 | Thermal converter | 1 | |
3 | Liquid filling machine | 1 | |
4 | Steel Coreheating furnace | 1 | |
5 | Dust collecting System | 1 | |
6 | Semi-auto horizontal band saw machine | GD4028A | 1 |
7 | Electric block | 2 | |
8 | Polishing machine | 3 | |
9 | Continuous caster | 2 | |
10 | Lathe | C6132AL | 2 |
11 | Extruding machine | XJ-800 | 1 |
12 | Extruding machine | XJ-630 | 3 |
13 | Bar materials heating furnace | RH-120 | 3 |
14 | Mould furnace | MH-30 | 2 |
15 | CNC lathe | CJK0630 | 9 |
16 | Direct-reading Spectrometer | QSN750 | 1 |
17 | Atomic absorption spectrophotometer | 361MC | 1 |
18 | Visible spectrophotometer | 722N | 1 |
19 | Direct-reading Spectrometer | LABSPARK 750A | 2 |
20 | Niton XL2 GOLDD XRF analyzer | Niton XL2 GOLDD XRF | 1 |
21 | Atomic emission spectrometer ICP-AES | Plasma | 1 |
Company Profile
Ningbo Yuxi light alloy Co.,ltd was established in 2003 and we are specialized in manufacturing Magnesium/AluminumExtrusion/casting products. The range of our product line, excellent quality & service, low price over the past ten years have made us one of the leading companies of its kind in China.
It’s our principal aim to provide the highest quality of materials and integrity of services, so our customer can focus all of their efforts in the more profitable services such as design, Marketing.
Taking advantage of the advanced technology and low labor cost, YUXI is always able to provide high quality products and integrity customer services backed with the most competitive price.
Please select us as your honest and reliable partner to save your money and time.
Factory occupation 26600 square meter
Total staff 120
Management & Technical staff 27
Capacity:
- Magnesium Casting: 1,500 tons per year
- Magnesium Extrusion: 1,200 tons per year
- Aluminum & Zinc casting: 2,000 tons per year
- Aluminum & Zinc extrusion: 1,500 tons per year
