Zinc reference electrode
Routine potential monitoring is an important part of cathodic protection maintenance program, an accurate, reliable, and consistent reference electrode is crucial for the potential monitoring.
Yuxi offers high level reference electrode which complys to the highest industry standards. Our reference electrodes include Copper/Copper Sulfate, Silver/Silver Chloride, High Purity Zinc. They are all available in buried and portable type.
YXRE04-Zinc Reference Electrode
Zinc is sometimes used as a reference electrode since the potential of zinc is relatively stable. Zinc is actually a pseudo-reference electrode since the potential of zinc can change as the environment changes. Zinc is not stable in carbonates or at high temperatures. For underground use, the zinc electrode is packaged in a cloth bag containing the same backfill as used around zinc anodes. In water, zinc electrodes are used bare.YXRE04 is zinc electrode made from 99.995 high purity zinc.
Specification:
Type |
Buried Type |
Bare Type |
Size: |
Zinc rod30mm dia. X 200mm Long Overall 150mm dia. 300mm Long |
Zinc rod30mm dia. X100mm long Overall 100mm dia. X 250mm long |
Lead wire: |
10m6mm2RHH-RHW black wire |
10m6mm2 RHH-RHW black wire |
Material |
Cotton bag |
High impact ABS |
Stability |
±10 millivolts with 0.3 microamps load. |
±10 millivolts with 0.3 microamps load. |
Working Temperature |
0°C to 55°C |
0°C to 55°C |
Company Profile
Ningbo Yuxi light alloy Co.,ltd was established in 2003 and we are specialized in manufacturing Magnesium/AluminumExtrusion/casting products. The range of our product line, excellent quality & service, low price over the past ten years have made us one of the leading companies of its kind in China.
It’s our principal aim to provide the highest quality of materials and integrity of services, so our customer can focus all of their efforts in the more profitable services such as design, Marketing.
Taking advantage of the advanced technology and low labor cost, YUXI is always able to provide high quality products and integrity customer services backed with the most competitive price.
Please select us as your honest and reliable partner to save your money and time.
Factory occupation 26600 square meter
Total staff 120
Management & Technical staff 27
Capacity:
- Magnesium Casting: 1,500 tons per year
- Magnesium Extrusion: 1,200 tons per year
- Aluminum & Zinc casting: 2,000 tons per year
- Aluminum & Zinc extrusion: 1,500 tons per year
