TY380-0PV404K Heavy off Road Dumper 80ton,off Road Vehicle,off Road Truck

Name: TY380-0PV404K Heavy off Road Dumper 80ton,off Road Vehicle,off Road Truck
Brand: MANNWELL, TONGYUN
SKU: 122967593

US$ 1 - 150,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Shanxi, China

Brand Name:

MANNWELL, TONGYUN

Model Number:

TY380-0PV404K

Jinan Mann-Well Commercial & Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

china main port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanxi, China

Brand Name MANNWELL, TONGYUN

Model Number TY380-0PV404K

Heavy off road vehicle
duty off road dumper,off road truck
6x4 Heavy off road vehicle
8x4 Heavy duty off road dumper

MODLE	TY380-0PV404K
DIRVE METHOD	6X4
CURB WEIGHT(KG)	25000
PAYLOAD(KG)	55000
TOTAL MASS(KG)	80000
DIMENSION(MM)	8820X3450X4100
MAX SPEED(KM/H)	50
MIN. CLEARANCE(MM)	380
MIN TURING RADIUS (M)	LESS OR EQUAL TO 11
MAX GRAND ABILITY (%)	40
APPROACH ANGLE/ANGLE OF DEPARTURE(°)	35/52
WHEELBASE(MM)	3950+1560
WHEEL TRACK(MM)	FRONT 2466, REAR2262
CAB	SIDE PALCED AND MINERAL CABINE
ENGINE MOLD	ISME420 30
DISPLACEMENT(L)	10.8
RATED HORSEPOWER(KW/PS)	306/420
MAX TORQUE /ROTATING SPEED(NM/MIN)	2010/1200
GEARBOX MODEL	ET-20109A, ERIK JOHNSON4500 AUTO
FRONT AXLE	16T
REAR AXLE	32TX2
EMISSION	EURO III
FRAME	320H X1020W X(10+8+6)MM, 510L STEEL
BRAKING SYSTEM	DOUBLE-WAY BRAKE WITH JACOBS
ELECTRONIC SYSTEMS	24V
AIR FILTER	THREE ELEMENTS DISSERT AIR FILTERS
FUEL TANKER CAPACITY (L)	400L
TYRE	14.00-25
CARGO BOX SIZE(M)	5.8 X3.2 X1.6(30M3)
CARGO BOX MATERIAL	Q700 HIGH STRENGTH STEEL PLATE
CARGO BOX MATERIAL THICKNESS (MM)	BOTTOM 10, SIDE 8
HYDRAULIC	FRONT LIFTING CHINA HYVA
MAX LIFTING ANGLE(°)	51
