Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > Chain Grate Coal Furnace

Chain Grate Coal Furnace

Name: Chain Grate Coal Furnace
Brand: XUETAO
SKU: 122965463
Availability: InStock

US$ 20,000 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

XUETAO

Model Number:

YLW

Contact Supplier Request Quote Chat Now

Wuxi Xuetao Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name XUETAO

Model Number YLW

Specifications

Model: YLW- MA
Easy Installation and Movement
Fuel: Coal or No smoke coal
Automatic Chain Grate

Specification

This kind of Chain Grate Coal Furnace is horizontal type. It consists with upper and below parts. Having reliable function and easy maintain. The automatic chain grate adjust easily.

The fuel can be coal and no smoke coal..

The output: 1,600,000kcal/h;2,000,000kcal/h;2,500,000kcal/h; 3,000,000kcal/h; 4,000,000kcal/h;5,000,000kcal/h; 6,000,000kcal/h;7,000,000kcal/h; 8000000kcal/h;10,000,000kcal/h.

Type Data Parameters	1860 MA	2400 MA	2900 MA	3500 MA	4000 MA	4700 MA	5800 MA	7000 MA	8200 MA	9400 MA	12000 MA
Rated heat output 10⁴ Kcal/h	160	200	250	300	350	400	500	600	700	800	1000
Designed pressure MPa	0.6	0.6	0.6	0.6	0.7	0.7	0.7	0.8	0.8	0.7	0.7
Max. working temperature°C	320	320	320	320	320	320	320	320	320	320	320
Thermal efficiency %≥	73	73	73	73	73	75	75	75	75	75	75
Cycle flow rate m³/h	160	160	200	200	260	260	300	340	400	520	600
Caliber of the pipe connected DN	150	150	200	200	200	200	200	250	250	300	300
Total power KW	75	85	100	110	130	150	190	210	231	252	320
Fuel variety	Coal No smoke coal
