smd led pcb module specfication
No. |
Item |
Parameter |
1 |
Input Voltage |
DC12V |
2 |
Power(Single module) |
1.0W(Max) |
3 |
LED Number(Single module) |
4PCS |
4 |
Max Connection Qty(PCS) |
20(MAX) |
5 |
IP Level |
IP65 |
6 |
Cover color & material |
Milky white PVC |
7 |
Size |
37*41*5.7mm |
8 |
Drive mode |
Constant drive |
9 |
Working temperature |
-20~+60°C |
10 |
Stock temperature |
-40~+80°C |
11 |
Warranty |
3year/15000H |
12 |
Weight(single module) |
245g |
smd led pcb module feature
1) Pure color, available in full range of single-color, red, yellow,blue,green,white etc.
2) Low power consumption, high intensity and stability.
3.Easy to install by the 3M tape on the PCB back.
4) Unique circuit design with strong resistance against static electricity ensures the stability of the strips for long lifespan guaranteed.
5) Easy connection with snap-in connectors
6) Solid-state, high stock and vibration resistant. No RF interference.
7) Long life 100,000 hours
8) Certificate: Rohs and CE
smd led pcb module Application:
1.Outdoor/Indoor Use
2.Cove Lighting
3.Path and contour lighting
4.Backlight for signage/ letters
5.Architectural lights for Canopy, Corridor, Window, Archwa.
6.Replacement of Fluorescent light
7.Decorative lights for holiday, event, show, exhibition.
our euipment show
