electric linear actuator 12v

Name: electric linear actuator 12v
Brand: KAIDI
Price: USD $500 - 2,000 / Set

FOB Price

USD $500 - $2,000 / Set

1 Set(Min.Order)

Supply Ability 5000 Set / Sets per Month
Port CHINA
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

KAIDI

Model Number:

BIQ-V

Packaging Details

Standard exporting package

Product Description

Specifications

1. Torque : 50 NM ~ 3000 NM
2. Operating time : 10 sec ~ 135 Sec .
3. Weatherproof: IP 65
4. Output: 4-20mA

Kaidi BIQ-V electric linear actuator 12v delivers a complete range of actuators suitable for all multi-turn valve applications requiring control and indication flexibility. It offers end users ever higher standards of performance, build quality and overall value.

Direct torque output range from 34 Nm (25 lbf ft) to 3,000 Nm (2,200 lbf ft).

Power supply	380VAC/50Hz/3ph, 220VAC/50Hz/1ph	Please statement for other power supply in order form
Input signals	DC4~20mA. DC24V. AC220V. Fildbus
Output signals	DC4~20mA.	6 status contacts can be configured at the local. 1 contacts for indicating remote or local. 1 contacts for indicating faults.
Contacts capability	250VAC/5A or 30VDC/5A
CPT load	≤750Ω
Output torque	see table 1
Output speed	see table 1
Safety grade	Watertight enclosure: IP68
Explosive proof	Exd II CT4
Environment temperature	-10°C~+70°C or optional: -30°C~+70°C
Lubrication	Senior lubricant
Install	Install flange conforms to the ISO5210:2001(GB/T12222-2005)(see table 3),the other configuration flange can be assembled yet according to user’s demand.
Wiring holes	One M40x1.5 and Two M25x1.5 spiral holes, cable diameter is 22~32mm , and water proof type adopts clamp tie-in; Explosion proof type adopts explosion proof tie-in or screw thread pipe.
