STRUCTURAL FEATURES:
The roll is made of chilled cast iron of vanadium and titanium alloys. (Rolls of G model are made of high grade steel with hard alloy welded on the surface.) The roll face is hard and anti-wear. Both the front roll and the back roll are fluted. The internal cavity of the roll is processed to ensure temperature well proportioned on the roll surface.
The machine is equipped with an overload protection device to prevent the major components from being damaged due to overloading.
The machine is also equipped with an emergency device. When an emergent accident happens, just draw the safety pull-rod, and the machine will stop immediately. It is safe and reliable.
APPLICATION:
The machine is applicable for breaking scrap rubber and virgin rubber. G mode is applicable for breaking scrap radial steel tires.
Technical Parameters:
Model & Spec. |
XKP-400 |
|
Working Diameter of F. Roll (mm) |
400 |
|
Working Diameter of B. Roll (mm) |
400 |
|
Working Length of F. & B. Rolls (mm) |
800 |
|
Linear Speed of F. Roll (m/min) |
19.3 |
|
Linear Speed Ratio of F. & B. Rolls |
1:1.27 |
|
Maximum Nip (mm) |
10 |
|
Output Capacity (Kg/Shift) |
1~1.3(24Mesh) |
|
Main Motor Power (KW) |
45 |
|
Speed Reducer |
NGW Planetary Hardened-gear Speed Reducer |
|
Overall Dimensions |
Length |
4490 |
Width |
1770 |
|
High |
1750 |
|
Note: Rubber powder sieve unit is optional for all the models above. | ||
