Rubber Grinding Mill
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Tire Machine
Tire Machine Type:
Tire Recycling Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Tire Machine
Tire Machine Type
Tire Recycling Machine
Place of Origin
Sichuan, China
Brand Name
YAXI
Model Number
ZXF-480B
Voltage
380V or as required
Power(W)
75kw
Dimension(L*W*H)
5500X2330X1780
Weight
19.5T
Certification
ISO9001
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Application:The machine is applicable for grinding scrap rubber.
APPLICATION:
The machine is applicable for grinding scrap rubber.
STRUCTURAL FEATURES:
The roll is made of chilled cast iron with vanadium and titanium alloys. The roll face is hard and anti-wear. Both the front roll and the back roll are plain rolls. The internal cavity of the roll is processed to make temperature well proportioned on the roll surface.
The machine is equipped with an overlaod protection device to prevent the major components from being damaged due to overloading.
The machine is also equipped with an emergency device. When an emergent accident happens, just draw the safety pull-rod, and the machine will stop immediately. It is safe and reliable.
| ModelSpecifications | ZKF-480A | ZKF-480B | ZKF-480D |
| Working Diameter of.F. Roll(mm) | 480 | 480 | 480(FIuted) |
| Working Diameter of B. Roll(mm) | 610 | 610 | 610(FIuted) |
| Working Length of F.&B. Rolls(mm) | 800 | 800 | 800 |
| Linear Speed of F. Roll(m/min) | 22 | 22 | 22 |
| Linear Speed Ratio of F.&B.Rolls | 1:2.1 | 1:2.1 | 1:2.1 |
| Maximum Nip(mm) | 15 | 15 | 15 |
| Output (Kg/h) | 150 | 150 | 150 |
| Main Motor Power(KW) | 75 | 75 | 110 |
| Speed Reducer | Inve rted-Y Speed Reducer | NGW Planetary Hardened-gear Speed Reducer | |
| Overall Dimension(mm) | Length 5450 | 5500 | 6280 |
| Height 2450 | 2330 | 2330 | |
| Width 1780 | 1780 | 2100 | |
| Weight(Kg) | 17000 | 19500 | 20000 |
