Specifications
YDJ-6300 Scrap Steel Shearing baler machine
YDJ series heavy duty hydraulic shearing machine,for a variety of light weight materials,production and living with scrap steel,light mental structure,a variety of plastic non-ferrous mental(steel,aluminum copper materials etc.) and shear compression packing;or above scrap direct compression packing.
Applications:
(1)Preload and cut waste
(2)Shear reinforcement
(3)Packaged thin material.
(4)Compression ,shear automobile body.
YDJ-6300 Scrap Steel Shearing baler machine
Main technical specification
1 |
Shearing cylinder |
Type |
YG530/400-900 |
Quantity |
1set |
||||
push force |
6300KN |
Stroke |
900MM |
||||||
2 |
Clamping cylinder |
Type |
YG180/120-700 |
Quantity |
2set |
||||
push force |
630*2KN |
Stroke |
700mm |
||||||
3 |
Lateral pressure cylinder |
Type |
YG220/160-1300 |
Quantity |
3sets |
||||
push force |
1000KN*3 |
Stroke |
1300mm |
||||||
4 |
Cover oil cylinder |
Type |
YG200/140-1600 |
Quantity |
3sets |
||||
push force |
800KN*3 |
Stroke |
1600mm |
||||||
5 |
Push cylinder |
Type |
YG220/160-6300 |
Quantity |
1set |
||||
push force |
1000KN |
Stroke |
6300mm |
||||||
6 |
Pressure Indoor Size |
6000*2000*1100MM |
|||||||
7 |
Metal Mass Size |
6000*720*600MM |
|||||||
8 |
System work force |
25Mpa |
|||||||
9 |
Scissors length |
4-7times/min |
|||||||
10 |
motor |
Type |
Y200L-4 |
Power |
30KW |
||||
Nominal Speed |
1470rpm |
Quantity |
6sets |
||||||
11 |
Piston Pump |
Type |
160YCY14-1B |
Nominal Pressure |
31.5Mpa |
||||
Nominal Outflow |
160ml/r |
Quantity |
6set |
||||||
YDJ-6300 Scrap Steel Shearing baler machine
