Specifications
Humidity display /Temperature control /Defrosting control /Lighting control /Fan control /Power switch /Setting Memorize /Self d| NTC sensor temperature controller YK-301 | |
| temperature control, humidity display equipment /The compressor/relay output control/Temperature and humidity double window display and control /Parameters of the lock/ Humidity display /Temperature control /Defrosting control /Lighting control /Fan control /Power switch /Setting Memorize /Self diagnose | |
| color | black |
| control range | -45~80°C |
| tempeature range | -45~80°C |
| resolution | 1°C |
| accuracy | 1°C |
| humidity display | 0~99%RH |
| accuracy | 3%RH |
| connecting line length | 1.5meter/ 2.0meter (Customized support) |
| display | lcd display, celsius |
| style | external,waterproof |
| working voltage | AC220V ±10% 50HZ/60HZ |
| output load | 30A/250VAC external (applied directly to a compressor) |
| lighting | 10A/250VAC |
| fan | 10A/250VAC |
| power consumption | less than 3W |
| temperature sensor | NTC-103*1pcs, 2meter length |
| humidity sensor | one humidity sensor |
| machine size | 176*41*43mm |
| hole size | 138*32.5mm |
| packing | standard exporting carton |
| shipment | Fedex, DHL, TNT, UPS, TOLL, EMS |
| paymnet | T/T, MoneyGram, PayPal, Western Union, Cash, Escrow |
About U-Control
We're the manufacturer and has been customizing digital thermometer and temperature controller for heating and refrigeration equipment manufacturers since 2004.
The products are UL, CE, CQC, TUV , ISO9001:2008 and RoHS approved.
Technical supply free, one year guarantee and whole life long maintenance.
