YK-302 Temperature and Humidity Controller/chocolate Temperature Control Machine

YK-302 Temperature and Humidity Controller/chocolate Temperature Control Machine photo-1
US$ 10 - 24 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YOUKONG
Model Number:
YK-301
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name YOUKONG
Model Number YK-301
Usage Industrial
Theory Resistance Thermometer
Accuracy 1°C
Temperature Range -45~80°C

Specifications

temperature control, humidity control /The compressor/relay output control/Temperature and humidity double window display and



NTC sensor temperature humidity controller YK-302

temperature control, humidity control /The compressor/relay output control/Temperature and humidity double window display and control /Parameters of the lock/  Humidity display /Temperature control /Defrosting control /Lighting control /Fan control /Power switch /Setting Memorize /Self diagnose
color black
control range  -45~80°C
tempeature range  -45~80°C
resolution 1°C
accuracy 1°C
humidity control range 0~99%RH
accuracy 3%RH
connecting line length 1.5meter/ 2.0meter (Customized support)
material of probe plastic
display lcd display, celsius
style external,waterproof
working voltage AC220V ±10% 50HZ/60HZ
output load 30A/250VAC external (applied directly to a compressor)
lighting 10A/250VAC
fan 10A/250VAC
power consumption less than 3W
temperature sensor NTC-103*1pcs, 2meter length
humidity sensor one humidity sensor
machine size 176*41*43mm
hole size 138*32.5mm









Packaging & Shipping





                                                                   Packing

 YK-302 temperature and humidity controller/chocolate temperature control machineYK-302 temperature and humidity controller/chocolate temperature control machineYK-302 temperature and humidity controller/chocolate temperature control machine





                                   About U-Control



We're the manufacturer and has been customizing digital thermometer and temperature controller for heating and refrigeration equipment manufacturers since 2004.



The products are UL, CE, CQC, TUV , ISO9001:2008 and RoHS approved.



Technical supply free, one year guarantee and whole life long maintenance.
