Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Industrial Machine Infinity Challenger Digital Flex Banner Printing Machine Fy-3206t

Industrial Machine Infinity Challenger Digital Flex Banner Printing Machine Fy-3206t

Name: Industrial Machine Infinity Challenger Digital Flex Banner Printing Machine Fy-3206t
Brand: Infiniti
SKU: 122925649
Availability: InStock

Industrial Machine Infinity Challenger Digital Flex Banner Printing Machine Fy-3206t thumbnail-1

Industrial Machine Infinity Challenger Digital Flex Banner Printing Machine Fy-3206t photo-1

US$ 8,000 - 15,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Plate Type:

Flatbed Printer

Place of Origin:

Guangdong, China

Contact Supplier Request Quote Chat Now

Guangzhou Caixu Digital Technology Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Plate Type Flatbed Printer

Place of Origin Guangdong, China

Brand Name Infiniti

Model Number FY-3206T

Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer

Automatic Grade Automatic

Voltage 220V

Gross Power 1500W

Dimensions(L*W*H) L4,650x W970 x H1550mm

Weight 591kg

Certification CE Certification

After-sales Service Provided Engineers available to service machinery overseas

infiniti/Challenger newly released printer FY-3206T & FY3208T

1, Equipped with 6 or 8 SPT 510/35PL

2, 6 color printing, high speed .

3, AC servo motor is used to run the carriage quicker and more stable.

4, Individual color cleaning minimizes the waste of the ink;

5, 3 way intelligent heater (pre/print/post) helps bring more vivid output;

6, The entire printing platform and the girder are made of the alloy-aluminum which is strong and flat.

parametre list:

Model		FY-3206T
Printhead		Drop on demand Piezo Head(SPT510-35PL)
Number of Printhead		6 Heads
Max Print Width		3200mm (10.5ft)
Print Speed	Draft	54m2/hr 360X360dpi 1Pass
	Production	44m2/hr 240X720dpi 2Pass
	Quality	27m2/hr 240x1080dpi 3Pass
	High Quality	16m2/hr 720x720dpi 4Pass
Media	Width	3300mm (10.8ft)
	Max.Weight	120kg
	Type	Frontlit, Backlit, Vinyl, Polyester, Window-Film, Mesh, Leather, Backlit Film, Blue Back Paper
	Thickness	4mm(Max.)
Heating System		3 way intelligent heater
Auto Media Feeding&Take-up System		Equipped
Ink	Type	Solvent, Eco-Solvent
	Capacity	1L or 5L per Color Main Tank
Auto Cleaning System		Positive Pressure Cleaning, Anti-Clogging Flash Function&Capping System
Print Interface		USB2.0
Power Specification		Printer :AC 220V, 50Hz 3.5A 770W/Heater: AC 220V,50HZ 9A 1980W
Operational Environment		Temperature20°C-28°C Humidity40%-60%
Compatible RIP Software		Photoprint, UltraPrint,Topaz,Wasatch,Caldera,Maitop
Dimension & Weight	Machine	L4,460 x W905 x H1,280mm; Net Weight: 348Kg
	Package	L4,650x W970 x H1550mm; Gross Weight: 591Kg

Pictures to reference :

This pictures were taken in our guangzhou warehouse . You are warmly welcomed to our warehouse check the quality and choose those you like . Any interest , please do not hesitate to contact us .

The front side of FY3206T . Two emergncy swiths in the both left and right side . In the right size there are temperature control. Ensure printing safely and smoothly .

The right side of printer . Top quality X Y motor . Keep stable runing .

Right side of printer : Indvividual color cleaning system . Light of printer .

Print head position

Inside looking of box .

Print head board

Good and strong flat table make sure the stable printing . 3 ways heating system to ensure the vivid color .

Back side of the printer

Inside looking of the printer box .

Machine always be packed in the safe wooden box to against damagad .

Printer should be strictly check by us before send out .

We always keep stcoking all kinds model of printer

Printer was packed by the wooden box with great protection and send to customers .

How to order?

Step 1. Contact with me about the details and product you need.

Step 2. Confirm the order to us, provide the following information, then we will send you Proforma Invoice (PI) for your reference.

Order Details ( Items and Quantity), Company Name, Contact Person, Address, Telephone, Sea port of destination

Step 3. Send payment T/T in advance and notify us (send Bank Slip to us)

Step 4. We will deliver the goods within 5 working days after receipt of your payment, and keep you informed about the order status.

Balance payment should be paid upon copy of B/L.On receipt of balance payment, we will send you original shipping documents by DHL and let you know the tracking number.

Step 5. Confirm to us upon receipt of order.
