Help CenterMolybdenum Steel Gate Valve
US$ 130 - 1,300
MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Gate
Pressure:
Other, PN100
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Standard
Structure
Gate
Pressure
Other, PN100
Power
Manual
Material
Other, molybdenum steel
Temperature of Media
Normal Temperature
Media
Oil
Port Size
2"-36"
Place of Origin
Zhejiang, China
Model Number
Z40W
Brand Name
GL valve
Application
Other, Industry
Molybdenum steel gate valve
Product Description
1.Pressure rate:PN100
2.Size range:2"-36"
3.Body material: molybdenum steel
4.Operated type:handwheel,bevel gear,electric etc.
Main Dimensions
| Desing And manufcture | Face to face/End to end | Flange Dimension | Butt welding dimension | Pressure and Temperature | lnspection and test |
| APl 600 | ASME B16.10 | ASME B16.5 | ASTM B16.25 | ASME B16.34 | APl 598 |
Pressure test
| Nominal Pressure | Shell Test | Water Seal Test | Air Seal Test | |||
| MPa | Lbf/in2 | MPa | Lbf/in2 | MDa | Lbf/in2 | |
| 150 | 3.1 | 450 | 2.2 | 315 | 0.5/7 | 60/00 |
| 300 | 7.8 | 1125 | 5.6 | 815 | ||
| 600 | 15.3 | 2225 | 11.2 | 1630 | ||
| 900 | 23.1 | 3350 | 16.8 | 2440 | ||
| 1500 | 38.4 | 5575 | 28.1 | 4080 | ||
| 2500 | 64.6 | 9367 | 47.4 | 6873 | ||
Main part material
| Body | ASTM A216 WCB | ASTM A351 CF8 | |||
| Wedge disc | WCB | CF8 | CF8M | Monel | |
| Stem | F6a | F304 | F316 | Monel | F304 |
| Wedge disc Sealing face | 13Cr 13Cr STL | 304 STL | 316 STL | Monel | 304 304 STL |
| Seat ring sealing face | 13Cr STL STL | 304 STL | 316 STL | Morel | 304 STL STL |
| Body | ASTM A351 CF3 | ASTM A351 CF8M | ASTM A351 CF8 |
| Wedge disc | |||
| Stem | F304L | F316 | F316 |
| Wedge disc Sealing face | 304L 304L STL | 316 316 STL | 316L 316L STL |
| Seat ring sealing face | 304L STL STL | 316 | 316L STL STL |
Packaging & Shipping
Certifications
FAQ
Enquiry Notice
The following details should be dated in your enquiry:
1) Size
2) Class
3) Body Material
4) Trim Material (Internal parts)
5) Connection type
6) Operated type
7) Sealing face
8) Tempreture
9) Medium
10)Design standard; Connection Standard
