Help CenterAPI CF8 Gate Valve
US$ 130 - 1,300
MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Gate
Pressure:
Other, 150Class-1500class
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Standard
Structure
Gate
Pressure
Other, 150Class-1500class
Power
Manual
Material
Casting
Temperature of Media
Normal Temperature
Media
Oil
Port Size
2"-36"
Place of Origin
Zhejiang, China
Model Number
Z40W
Brand Name
GL valve
Application
Other, Industry
API CF8 Gate Valve
Product Description
1.Pressure rate:class 150
2.Size range:2"-36"
3.Body material:CF8
4.Operated type:handwheel
Main Dimensions
| Desing And manufcture | Face to face/End to end | Flange Dimension | Butt welding dimension | Pressure and Temperature | lnspection and test |
| APl 600 | ASME B16.10 | ASME B16.5 | ASTM B16.25 | ASME B16.34 | APl 598 |
Pressure test
| Nominal Pressure | Shell Test | Water Seal Test | Air Seal Test | |||
| MPa | Lbf/in2 | MPa | Lbf/in2 | MDa | Lbf/in2 | |
| 150 | 3.1 | 450 | 2.2 | 315 | 0.5/7 | 60/00 |
| 300 | 7.8 | 1125 | 5.6 | 815 | ||
| 600 | 15.3 | 2225 | 11.2 | 1630 | ||
| 900 | 23.1 | 3350 | 16.8 | 2440 | ||
| 1500 | 38.4 | 5575 | 28.1 | 4080 | ||
| 2500 | 64.6 | 9367 | 47.4 | 6873 | ||
Main part material
| Body | ASTM A216 WCB | ASTM A351 CF8 | |||
| Wedge disc | WCB | CF8 | CF8M | Monel | |
| Stem | F6a | F304 | F316 | Monel | F304 |
| Wedge disc Sealing face | 13Cr 13Cr STL | 304 STL | 316 STL | Monel | 304 304 STL |
| Seat ring sealing face | 13Cr STL STL | 304 STL | 316 STL | Morel | 304 STL STL |
| Body | ASTM A351 CF3 | ASTM A351 CF8M | ASTM A351 CF8 |
| Wedge disc | |||
| Stem | F304L | F316 | F316 |
| Wedge disc Sealing face | 304L 304L STL | 316 316 STL | 316L 316L STL |
| Seat ring sealing face | 304L STL STL | 316 | 316L STL STL |
Packaging & Shipping
Certifications
FAQ
Enquiry Notice
The following details should be dated in your enquiry:
1) Size
2) Class
3) Body Material
4) Trim Material (Internal parts)
5) Connection type
6) Operated type
7) Sealing face
8) Tempreture
9) Medium
10)Design standard; Connection Standard
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2004
Factory Size
5,000-10,000 square meters
Total Employees
51 - 100 People
