Help CenterAutomatic Spray Welding Equipment
Related Products
Specifications
1.The body sheet metal structure, elegant appearance2.Import motor
3.External heat pipe
4.Vents fixed fast clip,jets welding
1.the main features of the machine as follows:
- The body sheet metal structure, elegant appearance;
Furnace tube using to import the whole titanium alloy welded, corrosion-resistant;
External heat pipe, to avoid the heating tube of tin corrosion, and at the same time easy to maintain;
Import motor, to ensure that the equipment for a long time and stable operation of;
The drive belt imported from Japan, belt, heat resistant to corrosion;
Vents above the laser head can quickly locate the site of welding;
Vents fixed fast clip, to facilitate the demolition;
The circuit is designed to take multiple layers of protection to ensure safe use.
2.The main technical parameters
Power supply: AC 220V 50/60HZ
Fuse: 220V-10A
Heat pipe: 200Wx6 = 1200
Motor: 25W (the governor and with thermal protection)
Jet stream: the speed of continuous changes in the function;
The motor speed control function; Precise control of slow stop function.
Tin temperature: 200 °C -350 °C
Temperature Probe: CA-K Thermocouple
Temperature control: closed-loop SSR control (± 1 ° C)
Temperature display: 3 digits, with temperature compensation PID control
Safety: Motor, within the lock
Tin bath: about 15 kg tin
Dimensions: LxWxH = 705x400x500
Net weight: 30Kg
