XCMG Telescopic Handlers for Sale XT680-170 (Rated Load: 4.5T, Lift Height:16.7m)

XCMG Telescopic Handlers for Sale XT680-170 (Rated Load: 4.5T, Lift Height:16.7m) thumbnail-1
XCMG Telescopic Handlers for Sale XT680-170 (Rated Load: 4.5T, Lift Height:16.7m) thumbnail-2
XCMG Telescopic Handlers for Sale XT680-170 (Rated Load: 4.5T, Lift Height:16.7m) photo-1
XCMG Telescopic Handlers for Sale XT680-170 (Rated Load: 4.5T, Lift Height:16.7m) photo-2
US$ 88,000 - 99,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
XCMG
Contact Supplier Request Quote Chat Now
Shanghai Longji Construction Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name XCMG
Model Number XT680-170
Type Other, Telescopic Handler
Power Souce Diesel Engine
Rated Loading Capacity 4500
Max. Lifting Height 16700
Min. Lifting Height 1063
Fork Length 1200
Fork Width 155
Overall Dimensions 5680*2500*2815
Certification CE\ISO\GOST
After-sales Service Provided Engineers available to service machinery overseas



XCMG Telescopic handlers for sale XT680-170 (Rated Load: 4.5T, Lift height:16.7m)

XCMG Telescopic handlers for sales

Cheap telescopic handlers

Hot selling to Africa, South America & Middle East ,etc.



DescriptionParameter Unit
Working weight13500kg
Engine power82kW
Max.capacity4500kg
Max.lift capacity to full height2269kg
Max.lift capacity at full reach453kg
Lifting height16700mm
Max.reach at full height1063mm
Max.forward reach12600mm
Wheel base3900mm
Tread2060mm
Min.ground clearance400mm
Overall length(backend to frok)6890mm
Max.length(tail to the front tires)5680mm
Max.width(including outrigger)2500mm
Max.height(including toplight)2815mm
Fork length1200mm
Length of suspension1055mm
Adjust angle of frameLeft10°
Right10°
Departure angle46°
Foront tilt angle of attachments90°
Back tilt angle of attachments18°
Max.depression angle(outrigger not on ground)-4°
Max.elevation(outriggers on ground)73°
Cab internal width945mm
Max.traction(without load)74.73kN
Min.turning radius(tires lateral)4860mm
Max.climbing ability33.2°
Traveling speedForward Ⅰ6.41km/h
Forward Ⅱ10.64km/h
Forward Ⅲ22km/h
Forward IV37.17km/h
Back Ⅰ6.37km/h
Back Ⅱ10.59km/h
Back Ⅲ21.8km/h
Back IV37.04km/h

 XCMG Telescopic handlers for sale XT680-170 (Rated Load: 4.5T, Lift height:16.7m)XCMG Telescopic handlers for sale XT680-170 (Rated Load: 4.5T, Lift height:16.7m)
