XCMG 215C of Excavator Machinery

Name: XCMG 215C of Excavator Machinery
Brand: XCMG
SKU: 122878773
Availability: InStock

US$ 50,000 - 300,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

XCMG

Model Number:

XE215C

Shanghai Longji Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number XE215C

Condition New

Moving Type Crawler Excavator

Operating Weight 21450KG

Bucket capacity 1.0

Maximum Digging Height 9640

Maximum Digging Depth 6655

Machine Weight 21450

Max Digging Radius 9925

Rated Speed 5.5/3.3km/h

Certification ISO9001,SGS,CE

After-sales Service Provided Overseas service center available

XCMG 215C excavator machinery

XE 215C XCMG excavator specifications

Model		Unit	XE215C
Operating weight		kg	21450
Standard bucket capacity		m³	0.8~1.0
Engine	Engine Model	/	ISUZU BB-6BG1TRP
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	√
	Air to air intercooler	/	×
	No. of cylinders	/	6
	Rated power/speed	kw/rpm	106.5/1950
	Max. torque/speed	N.m	551/1600
	Displacement	L	6.494
The main performance	Travel speed	km/h	5.5/3.3
	Swing speed	r/min	13.3
	Max. gradeability	/	≥35
	Ground pressure	kPa	45.5
	Max.Bucket digging force	kN	138
	Max.arm crowd force	kN	103
	Max.traction force	kN	184
Hydraulic system	Main pump	/	2 Plunger pump
	Rate flow of main pump	L/min	2×206
	Max pressure of prime relief valve	MPa	31.5/34.4
	Max pressure of travel system	MPa	34.3
	Max pressure of swing system	MPa	28
	Max pressure of pilot system	MPa	3.9
Oil capacity	Fuel tank capacity	L	360
	Hydraulic tank capacity	L	220
	Engine lubrication	L	25
Overall dimensions	A Overall length	mm	9525
	B Overall width	mm	2990
	C Overall height	mm	3000
	D Overall width of upperstructure	mm	2710
	E Track length	mm	4270
	F Overall width of undercarriage	mm	2990
	G Crawer width	mm	600
	H Track length on ground	mm	3462
	I Crawer gauge	mm	2390
	J Clearance under counter weight	mm	1050
	K Ground clearance	mm	470
	L Min.tail swing radius	mm	2750
Working range	A Max. digging height	mm	9640
	B Max. dumping height	mm	6800
	C Max. digging depth	mm	6655
	D 8inch horizonal digging depth	mm	6470
	E Max. vertical wall digging depth	mm	5695
	F Max. digging reach	mm	9925
	G Min. swing radius	mm	3530
	Angle of arm deflection	Degree
