XCMG Excavator XE15 of Mini Excavator for Sale

Name: XCMG Excavator XE15 of Mini Excavator for Sale
Brand: XCMG
SKU: 122878621
Availability: InStock

US$ 14,000 - 48,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangxi, China

Brand Name:

XCMG

Model Number:

XE15

Shanghai Longji Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangxi, China

Brand Name XCMG

Model Number XE15

Condition New

Moving Type Crawler Excavator

Operating Weight 1640kg

Bucket capacity 0.044m3

Maximum Digging Height 3615mm

Maximum Digging Depth 2320mm

Machine Weight 1730kg

Max Digging Radius 3915mm

Rated Speed 4.4 / 2.4km/h

Certification CE/ISO/GOST

After-sales Service Provided Engineers available to service machinery overseas

XCMG excavator XE15 of mini excavator for sale (Bucket Capacity: 0.044m3, Operating Weight: 1640kg)

XCMG mini excavator fo sale

cheap mini excavator for sale

good mini excavator for sale

Equipped with quality sprocket, idlers and track guards.

Model			XE15
Operating weight		kg	1640
Standard bucket capacity		m³	0.044
Engine	Engine Model	/	3TNV82A
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	×
	Air to air intercooler	/	×
	No. of cylinders	/	3
	Rated power/speed	kw/rpm	16.5/2200
	Max. torque/speed	N.m	86.5/1320
	Displacement	L	1.33
The main performance	Travel speed	km/h	4.4/2.4
	Swing speed	r/min	11
	Max. gradeability	/	30°
	Ground pressure	kPa	23.8
	Max.Bucket digging force	kN	13.9
	Max.arm crowd force	kN	8.8
	Main pump	/	Japan nachi
Hydraulic system	Rate flow of main pump	L/min	2×19.8+14.1
	Max pressure of prime relief valve	MPa	24
	Max pressure of travel system	MPa	21
	Max pressure of swing system	MPa	18
	Max pressure of pilot system	MPa	3.3
	Fuel tank capacity	L	20
Oil capacity	Hydraulic tank capacity	L	29
	Engine lubrication	L	5.5
	A Overall length	mm	3760
Overall dimensions	B Overall width	mm	1080
	C Overall height	mm	2400
	D Overall width of upperstructure	mm	1080
	E Track length	mm	1578
	F Overall width of undercarriage	mm	1080
	G crawer width	mm	230
	H Dozer black(width/height)	mm	1080×225
	I Tumbler distance	mm	1217
	J Crawer gauge	mm	850
	K Clearance under counter weight	mm	472
	L Ground clearance	mm	180
	M Min.tail swing radius	mm	1190
	A Max. digging height	mm	3615
Working range	B Max. dumping height	mm	2480
	C Max. digging depth	mm	2320
	E Max. vertical wall digging depth	mm	1520
	F Max. digging reach	mm	3915
	G Min. swing radius	mm	1675
	H Max.dozer lifting height	mm	220
	I Max.dozer cutting depth	mm	240
	Angle of arm deflection	Degree	70/50
