Help CenterSingle Piont Cabinet Solder Paste Dispenser
Related Products
-
Single Piont Cabinet Pcb DispenserUS$ 7,000 - 10,500MOQ: 1 Set -
Desktop Rotation Axis Automatic Soldering RobotNegotiableMOQ: 1 Set
-
Desktop Automatic Gule Dispensing Robot for ExporyNegotiableMOQ: 1 Set
-
Automatic Gule Dispensing RobotNegotiableMOQ: 1 Set
-
Desktop-type Dispensing RobotNegotiableMOQ: 1 Set
Specifications
lder paste dispenser2.English keyboard operation
3.easy to learn and easy to understand
4.single point
5.cabinet
Product feature:
3 d linear circular interpolation function ,precision Cornering Motion
High repeatedly position precision:+/-0.01mm
The ball srew LEAD compensation and X-Y linear compensation function
Can use touch screen and PC operate
specification :
Trip :X axis :300mm Y axis :300mm Z axis :100mm
The scope of work :300*300mm work space
Driven ways : Stepping motor
Speed :500MM/SEC
Carry weight:X axis :15KG Z axis :15KG
Z axis motor:use BRACK motor ,the BRACK motor can stoping move when cut power,and protecting products.
Controller :within muilt axis controller
Interpolation function :3 d linear circular interpolation function
Installation : no corrosive,volatile gase and acid oily
Power :single-phase AC220V+/-10% 50/60HZ
Key part:
Sevro motor : Japan Yasukawa
Driver: Japan Yasukawa
Ball srew :Japan NSK
Move Controller and program software are adopt korea technology
Germany import cable Use Chinese or English touch screen programming operating system
