Industrial Ultrasonic Stencil Cleaning Machine

Industrial Ultrasonic Stencil Cleaning Machine thumbnail-1
Industrial Ultrasonic Stencil Cleaning Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
SAM
Contact Supplier Request Quote Chat Now
Shenzhen SAM Electronic Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen /Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Guangdong, China
Brand Name SAM
Model Number SM-8160
Feature Critical Cleaning / Residue Free
Fuel Electric
Certification CE
Cleaning Process Solvent Cleaning
Cleaning Type Industrial Ultrasonic Cleaner
Industry Used Electronic Industry
Material Metal / Coil
Power(W) 10KW
Dimension(L*W*H) 1220mm*700mm *2200mm
After-sales Service Provided Engineers available to service machinery overseas

Features



Patent design, close contacting ultrasonic combining with spray cleaning, the stencil is no need to dip into the tank



The stencil moves up and down with a gap 0.5-2 mm between the ultrasonic source with the cleaning agent fl ows by



High pressure air knives blowing the stencil closely during the lift makes the drying time very short



Efficiently clean fi ne printing pitch and apertures with the solder paste and glue



The cycle time is less than 10 min for the solder paste and 15 min for the glue



PLC control, two modes, simple operation with buttons, safe and reliable, easy maintenance



MPC technology with fi ltration system, low running cost and environment-friendly



Specifications



External dimensions:1220mm(L)×700mm(W) ×2200mm(H)



Spraying chamber dimensions:870mm(L)×152mm(W) ×870mm(H)



Max stencil size :736mm*736mm*40mm(L*W*H)



Min stencil size : 550mm*500mm*30mm(L*W*H)



Clean agents : DI water + water-based cleaner



Ultrasonic power :1.8KW



Ultrasonic frequency :40KHZ



Water pump pressure : 0.2~0.3Mpa



Volume of tank :30L



Heating power : 4KW



Work temperature: room temperature~60℃



Fans power : 3KW



Voltage/Hz:380V AC/50HZ



Power:10KW



Weight:350 kg
