Specifications
Our experienced design engineers are using CAD/UG/PRO-E software programs in order to develop perfect toolsOur Yongmao is specialized in making pipe fitting plastic injection mould, we have the experience of mould making for10 years with very skilled and excellent working team. Our products include PVC drainage-sewage,PVC water supply,PVC insulating electrical ,PVC rainwater system,PE electro fusion,PE butt fusion,PE compression,PE corrugated,PP drainage PP sewer system and other product material. With your drawings and designs,we are able to make whatever mould you want, and we provide the best service and lowest price.
General Mold Specifications:
Name | Pipe fitting mould |
mould material | P20,H718,45#,2316 |
Plastic material | PVC,PPR,PP.PE,ABS,POM,PPCR…etc |
Steel of Cavity & Core | DIN 1.2316/ DIN 1.2738/DIN 1.2344 /M300/ 718/ P20..etc |
Steelof Mouldbase | S50C.LkM standard,HASCO,DME ect. |
Nos of Cavity | 1-n, or Customized |
Hardness of Cavity & Core | 42-45HRC |
Hardness of Wear Parts | 42-48HRC |
Core pulling system | Motor /oil cylinder/ stripping plate, angel pin…etc |
Mould Accessories | DME/HASCO Standard … |
Cooling system | In core baffle cooling and in cavity plate chain drilling type cooling |
Surface finish | Diamond polish, |
Molding life | 500,000-1,200,000shots |
Runner | Cold or Hot |
Trade & Market
Main arkets: | North America |
Export Percentage: | 90% - 100% |
Pipe fitting moulding :
1. Samples/Drawings & requirement from you
2. Mould design: we will communicate and exchange the opinion with you after you place an order.
3. Material Purchase: Steel cutting and Mould base tooling.
4. Assembling.
5. Inspection of mould: following and controlling the tooling processing.
6. Mould testing : we will inform you the date, than we will send you the inspection report of the sample and the injection parameters to you.
7. Your instruction and confirmation for shipment.
8. Readymade mould before packing.
