90ZYT-102WJ 12V 24V 350W DC Worm Gear Motor
US$ 37 - 99
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
DYD MOTOR
Model Number:
90ZYT-102WJ
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai; Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
63JW/63ZY 100W High Voltage Swing Gate DC Motor 12v 5000rpmUS$ 30 - 120MOQ: 50 Pieces -
63JW/63ZY 12v 100W dc Motor for Winch 3000rpmUS$ 30 - 120MOQ: 50 Pieces
-
63ZY127-63JW 12V DC Worm Gear Motor With EncoderUS$ 38 - 120MOQ: 50 Pieces
-
115ZY245/RV050i50 High Efficiency 12 Volt Worm Gear Motor 1 2 hpUS$ 145 - 900MOQ: 20 Pieces
-
63JW/63ZY 12v 100w Worm Drive Gear Motor dcUS$ 27 - 100MOQ: 50 Pieces
Place of Origin
Zhejiang, China
Brand Name
DYD MOTOR
Model Number
90ZYT-102WJ
Usage
Boat, Electric Bicycle, Fan, Home Appliance, Other
Certification
CCC, CE, ROHS, Other, CCC, CE, ROHS, ISO9001
Type
Gear Motor
Torque
Up to 120N.m
Construction
Permanent Magnet
Commutation
Brush
Protect Feature
Other, Totally Enclosed, Enclosed
Speed(RPM)
20 ~ 900rpm
Output Power
350W
Voltage(V)
12 ~ 400V DC
Efficiency
IE 1
DC WORM GEARED MOTOR 90ZYT/102WJ TYPICAL SPECS.:
Voltage 12V DC
Current approx. 34A
Final Output Power 150W
Rated Speed 65RPM
Rated Torque 22.5N.m
Voltage 90V DC
Final Output Power 200W
Rated Speed 315RPM
Rated Torque 6N.m
Operation Mode S1
High Temp. & Humidity Use
CARAVAN / TRAILER MOVER GEAR MOTOR SPECS AND FEATURE:
Voltage 12V DC
Rated Current 48A
No-Load Speed 4000RPM / 80RPM
Rated Speed 3250RPM / 65RPM
Rated Torque 0.9N.m / 22.5N.m
Motor Rated Output Power 350W
Gear Ratio 50/1
