Hot selling home car scissor lift,promotion mini scissor jack

TLT632AF Ultra-thin small scissor lift

This lift is designed for the purpose of lifting light vehicles(with low profile) under 3.2

tons for vehicle test, service and cleaning.

Feature

Ultra-tin 3t small scissor vehicle lift.
The platform is extendable.
Ultra-thin structure design is applicable for on-ground
arrangement ,technical cooperation with.Italy ,four hydraulic
cylinders design ,convenient for demounting tyres and repairing
chassis.
Hydraulic interlocking and anti-explosion safety device makes it
stable and reliable operation.
Bilateral hydraulic synchronizing system ensures high
synchronization performance.
Travel limit safety device ,protects machine from being damaged.
All moving points adopt automatic lubricating oil-free bearing for
ensuring long lifespan.
Oil hose anti-explosion device.
CE-STOP function with safety alarm beep would automatically
warn operators to keep safe distance from lift when it lowers to
400mm high from ground.
CE certificated

Specification

Rated load:3200kg
Lifting height:2000mm
Initial height: ≤110mm
Lifting time:≤60s
Lowering time:≥20s
Runway width:620mm
Runway length:1460~2060mm
Advised distance between two runways: 800mm
Overall width:2040mm
Safety method:Mechanical safety lock + pneumatic release
Motor power :2. 2kw
Motor voltage:3 phase/380v or Single phase/220V
