TD-V100 Best Quality Walkie Talkie Amature

TD-V100 Best Quality Walkie Talkie Amature thumbnail-1
TD-V100 Best Quality Walkie Talkie Amature photo-1
US$ 25 - 35 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TID
Model Number:
TID-V100
Contact Supplier Request Quote Chat Now
Guangzhou Tiger Electron Science & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen Guangzhou Dubai Hong Kong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name TID
Model Number TID-V100
Type Handheld
Dimensions 100*55*32mm
Frequency Range 400-430 MHz 400-480MHz
Storage Channel 128
Talk Range 5-7km



      TD-V100 Best quality walkie talkie amature







TD-V100 Best quality walkie talkie amature



  • scrambler function (optional)
  • Multi and priority channel scan function
  • high / low power control
  • channel name setting
  • TOT(Time-out-timer)







TD-V100 Best quality walkie talkie amature





Our Services


Trail order is acceptable, all the products are best quality with 18 months warranty. We promise small quantity can be ship out once receive payment, big quantity can be shipping out within 1 week after receive payment. We also can support OEM/ODM.



Main Functions of  ham radio handheld:

  • New Style Dot Matrix LCD Display ham radio
  • ANI CODE(PTT ID)
  • 128 memory channels puxing 777 radio
  • full-function keypad MT777 walkie talkie
  • Sound Alarm
  • three color LCD backlight display px-777 radio
  • Scrambler
  • Emergency Alarm
  • Channel Annunciation
  • Program alphanumeric channel name
  • Compact Size and Light Weight
  • Wider Band Coverage
  • Low Battery Alert for sale vhf radio
  • PC Programmable 350MHz walkie talkie
  • Large Capacity Li-ion Battery for motorola mt777 radio
  • CTCSS/DCS
  • High/Low Power Switchable
  • Auto Power-saving
  • Channel Spacing Selectable
  • Busy Channel Lockout (BCLO)
  • Squelch Level Programmable
  • Voice-operated transmission (VOX)
  • Multiple Scanning
  • Low Battery Alert
  • Time-out Timer (TOT)
  • Monitor
  • Wired Clone
  • Squelch Tail Elimination
  • High-quality Audio
  • Rugged and Durable (Option)
  • Keypad/LCD Back-lit Switch
  • One-key Emergency Call
  • Water Protection Class IP66 (Option)




1). Specification of 5watt ham radio walkie talkie( TD-V100)



1). Frequency Range

136-174Mhz ,245-246MHz,400-470MHz,445MHz-520MHz

2). Channel Capacity128
3). Channel Spacing5,10,12.5,20,25,30,50KHz optional
4). Operation VoltageDC7.2V Li-ion
5).Mode of operationsimplex or semi-duplex
6).Antenna impedance50Ω
7).Operating Temperature-20~50 °c
8). Dimension(H*W*D)(Without Antenna)115*60*32MM
9). Weight(With Antenna & Battery)210g



2).Accessories

1).Battery Pack1 set
2.Antenna1 set
3).Charger1 set
4).AC Adapter1 set
5).Belt Clip1 set
6).Hand strap1 set



TD-V100 Best quality walkie talkie amature



3).Transmitter

1). RF power output≤5W
2). Current≤1.6A
3). Maximum deviation≤5KHz
4). Frequency stablity≥±2.5ppm
5). Spruious radiation≤7.5 μW
6). Modulation charter1dB~3dB
7).Modulation distortion≤5%
8).Occupied bandwidth≥60dB



4).Receiver

1). RF sensitivity0.2μV
2). Audio distortion≤10%
3). Audio power≥500Mv
4). Selectivity≥65dB
5. Co-channel suppression≥-8dB
6).Adjacent channel selectivity≥60dB
7).Intermediation response≥60dB
8).Spurious response≥55dB
9).Blocking≥85dB





TD-V100 Best quality walkie talkie amature



TD-V100 Best quality walkie talkie amature

TD-V100 Best quality walkie talkie amatureTD-V100 Best quality walkie talkie amatureTD-V100 Best quality walkie talkie amatureTD-V100 Best quality walkie talkie amatureTD-V100 Best quality walkie talkie amatureTD-V100 Best quality walkie talkie amature

TD-V100 Best quality walkie talkie amatureTD-V100 Best quality walkie talkie amature





TD-V100 Best quality walkie talkie amature



Payment Terms



1. 100% T/T Advance

2. 100% Western Union Advance

3. 100% Pay pal Advance



Shipping Terms



1. EX-works Guangzhou

2. EX-works Hongkong

3. EX-works Xiamen

4. EX-works Dubai



Shipping Method



The delivery can by air/Sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS…



Lead time:



Most of our product have ready stock, sample order is ready any time, and bulk order depend on how many pcs you want.



Packaging :



Unique packaging with durable ,environmental , beauty design character (plastic bag color gift box).
