Specifications
2x4 HDMI Amplifier Splitter2x4 HDMI Amplifier Splitter
The HDMI Amplifier Splitter allows two HDMI devices to be switched easily into some HDTV HDMI compatible monitors or projectors. Simply connect your HDTV displays to the Splitter’s display outputs.
The HDMI Splitter can also be placed at the end of a long HDMI cable to regenerate the HDMI signal.
The HDMI Amplifier Splitter offers solutions for HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
FEATURES
The series of the HDMI Amplifier Splitter have many features that enable them to perform in a superior manner. Among those features you will find:
Easy to Use: Install in seconds, no need for setting
Switching: Inputs could be switched between two HDMI Source.
Supports the Video Amplifier Bandwidth up to 2.25Gpbs/225MHz
Stackable (Daisy chained): Large distribution achieved by stacking the HDMI Amplifier Splitter.
HDCP support
FCC CE Certified
SPECIFICATIONS
Signal Inputs/Output |
|
Input Video Signal |
0.5-1.0 volts p-p |
Input DDC Signal |
5 volts p-p (TTL) |
Video Amplifier Bandwidth |
2.25Gbps/225MHz |
Vertical Frequency Range |
60Hz |
Digital Signal I/O |
|
HDMI Compliance |
HDMI 1.3b |
Resolutions(HDTV) |
|
Interlaced(50&60Hz) |
480i,576i,1080i |
Progressive(50&60Hz) |
480p,576p,720p,1080p |
Mechanical |
|
Size(W-H-D) |
|
Weight(Net) |
|
Warranty |
|
Limited Warranty |
1 Year Parts and Labor |
Environmental |
|
Operating Temperature |
0°C to +70°C |
Operating Humidity |
10% to 80 % RH (no condensation) |
Storage Temperature |
-10°C to +80°C |
Storage Humidity |
5% to 90 % RH (no condensation) |
Power Requirement |
|
External Power Supply |
5V DC@2*2(2A),2*4(2.5A);2*8(3A) |
Power Consumption |
15 Watts (max.) |
Regulatory Approvals |
|
Converter Unit |
FCC,CE,UL |
Power Supply |
UL,CE,FCC |
Accessories Adapter |
|
AC Power Adapter |
US standard, UK standard and so on |
User Manual |
|
