Help CenterHigh Quality Auto Work 10A Solar Charge Controller
Related Products
Specifications
1 Warranty 3years2.payment term DA. DP. LC.
3. Pass CE UL ISO certificate
4.Delivery time 15days.
5.25years history of fa
Specifications:
Model |
GT5 |
GT10 |
GT20 |
GT30 |
GT40 |
GT60 |
GT100 |
|
Rated Charge current(A) |
5 |
10 |
20 |
30 |
40 |
60 |
100 |
|
Rated DC voltage(V) |
12/24 |
12/24 |
12/24/ 48/96 (optional) |
12/24/ 48/96 (optional) |
48/96 (optional) |
48/96 (optional) |
48/96 (optional) |
|
Solar input |
Max voltage(V) |
42 |
42 |
21/42/ 84/168 |
21/42/ 84/168 |
84/168 |
84/168 |
84/168 |
Battery |
Over charge protective voltage(V) |
28.6 |
28.6 |
28.6/57.2/114 |
28.6/57.2/114 |
57.2/114 |
57.2/114 |
57.2/114 |
Over charge recover voltage(V) |
27.4 |
27.4 |
27.4/54.8 |
27.4/54.8 |
27.4/54.8 |
27.4/54.8 |
27.4/54.8 |
|
Constant charge voltage(V) |
27 |
27 |
27/54 |
27/54 |
54 |
54 |
54 |
|
Over discharge alarm voltage(V) |
20 |
20 |
20/40 |
20/40 |
40 |
40 |
40 |
|
Others |
Environment Humidity and temperature |
0-90% No condense,55°C |
||||||
Protective Functions |
Protection against anti-charge at night,battery over charge,over discharge protection,Joint-reversed of solar modules |
|||||||
Control method |
PWM |
|||||||
Size :D*W*H(mm) |
214*120*55 |
214*120*55 |
214*120*55 |
214*120*55 |
235*150*70 |
260*170*140 |
370*290*140 |
|
Package:D*W*H(mm) |
240*138*82 |
240*138*82 |
240*138*82 |
240*138*82 |
275*170*95 |
310*220*190 |
395*345*205 |
|
N.W/G.W(kg) |
0.6/0.8 |
0.6/0.8 |
0.6/0.8 |
0.6/0.8 |
1.3/1.5 |
2.5/2.9 |
5.4/6.6 |
|
Remark: if the hybrid system, the solar panel and wind turbine output need the same, then the system can work .such as if 1KW wind turbine output is 48V, solar panel output also need 48V.
Warranty:1 year
Delivery time:3-5 days for sample
