Auto Lamp Vacuum Coating Machine/metalizing Equipment/plating Machine

Name: Auto Lamp Vacuum Coating Machine/metalizing Equipment/plating Machine
Brand: VAKIA
SKU: 122750191

US$ 60,000 - 160,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, sputtering coating machine

Substrate:

Aluminum

Shanghai Vakia Coating Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, sputtering coating machine

Substrate Aluminum

Coating Vacuum Coating

Place of Origin Shanghai, China

Brand Name VAKIA

Model Number MSC1400

Voltage 380v

Power(W) 40kw

Dimension(L*W*H) 4x4x2m

Weight 5t

Certification ISO9001:2008

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Model Function	VAKIA -MSC -700	VAKIA -MSC -900	VAKIA -MSC -1000	VAKIA -MSC -1250	VAKIA -MSC -1400	VAKIA -MSC -1600
Vacuum Chamber Inner Size	φ700 *H900 mm	φ900 *H1100 mm	φ1000 *H1200 mm	φ1250 *H1350 mm	φ1400 *H1600 mm	φ1600 *H1800 mm
Structure of Vacuum Chamber	Vertical double door,Vertical Front Door Structure,Back Pump-out System
Material of Vacuum Chamber	Superior Stainless Steel Chamber
Ultimate Vacuum	6.0×10^-4Pa
Pump-out Time(no-load)	From air to 8.0×10^-3Pa≤15min
Vacuum Acquisition System	Diffusion pump or molecular pump+Roots pump+Mechanical pump+Holding pump(The specification can be selected according customer’s demand)
Coating Style	magnetron sputtering coating
Kinds of Film	metal film,reaction film,compound film,multi-film,semi-conductor film
Cover Area	W2m×L3m	W2.5m×L3.5m	W3m×L4m	W4m×L5m	W4.5m×L6m	W5m×L7m
