Long service life mppt solar charge controller 36v 30a
It is a new type advanced solar charge controller produced by our company, which using MPPT technology, the charging efficiency improved 30% more than PWM Charging mode, it saves more than 30% solar panel and saves much cost for users. This type Advanced Solar Charge Controller has perfect functions, it helps charging for various types of battery. Using three period charging mode,Intelligent heat dissipation control,99% conversion efficiency and other advantages, our mppt solar charge controller is widely used for solar off grid system(independent system).
*Controller will work when input voltage is bigger than battery bank voltage, or it won’t work.
*Controller will stop working when input voltage is bigger than 130V(M48-30),170V(M48-40,M96), it needs to be powered off, the input voltage is adjusted to less than 130V(M48-30),170V(M48-40, M96), restart and then controller can work again.
*If the load current exceeds the upper limit of the controller, several controllers can be connected in parallel,and connect the input ends to battery at the same time,but the input ends of each controller must be independent access, and meet the range of single controller operating parameters, or controller will be burned to damage.
Mode |
M48-30 |
M48-40 |
M96-30 |
M96-40 |
Charging Mode |
MPPT |
|||
Charging Method |
Three period charging mode(constant current, constant voltage and float) |
|||
Input Voltage Range |
23V-130V |
23V-170V |
23V-170V |
23V-170V |
Output Voltage Range |
8V-60V |
8V-60V |
8V-120V |
8V-120V |
Battery bank voltage |
DC12V/24V/36V/48V/96V,( freely setting according to right condition ) |
|||
Controller output voltage Setting |
Please check the system voltage for reference,to finalise the output voltage setting. |
|||
Output Current Range |
0-30A |
0-40A |
0-30A |
0-40A |
Soft-start time |
≤5S |
|||
Dynamic response recovery time |
500us |
|||
overall efficiency |
96%—99% |
|||
PV module utilization |
≥99% |
|||
Battery Type |
Battery, lithium battery, etc. |
|||
Electrical Parameters | ||||
Isolation type |
Non-Isolated |
|||
Working temperature range |
-20℃~ +40℃ |
|||
Cooling Method |
Air cooling force, fan speed is automatically adjusted by the internal temperature |
|||
Humidity range |
0%~85% (NC) |
|||
Work Altitude |
≤4000m |
|||
Interface and appearance | ||||
Terminals |
TC series fence type wiring |
|||
Color |
Yellow |
|||
Display |
LCD |
|||
Language |
English |
|||
Data communication |
GPRS/RS232/R485(Optional) |
|||
Protection Level |
IP20 [Indoor] |
|||
Noise [dB] |
<30 |
|||
Mounting |
Wall mounting type |
|||
Dimensions (W*D*H) [mm] |
250*250*110 |
|||
Net Weight |
3kg |
|||
| Battery type | Battery Cell Voltage(V) | Battery pack system voltage (V) | Rated Output Voltage(V) |
| Lead-acid battery | 2/Cell | 12/(6 Cell ) | 14.4 |
| 24 | 28.8 | ||
| 36 | 43.2 | ||
| 48 | 57.6 | ||
| 96 | 115.2 | ||
| Gel Battery | 2/Cell | 12/(6 Cell ) | 14.4 |
| 24 | 28.8 | ||
| 36 | 43.2 | ||
| 48 | 57.6 | ||
| 96 | 115.2 | ||
| LFP Battery | 3.2/PCS | 12/(4 PCS ) | 14.4 |
| 24 | 28.8 | ||
| 36 | 43.2 | ||
| 48 | 57.6 | ||
| 96 | 115.2 | ||
| Lithium battery | 3.7/PCS | 12/(3 PCS ) | 12.5 |
| 24 | 25 | ||
| 36 | 37.5 | ||
| 48 | 50 | ||
| 96 | 100 | ||
| Lithium titanate battery | 2.4/PCS | 12/(5 PCS ) | 13.75 |
| 24 | 27.5 | ||
| 36 | 41.25 | ||
| 48 | 55 | ||
| 96 | 110 |
