High Reflective Plastic Silver Magnetron Sputtering Deposition Ag Plating Equipment
BENEFITS
1) Low investment and high payback for owner
2) To provide effective training for users: equipment operation & coating processes
3) High volume production, fast cycle (20-30mins/batch),robust structure system
4) Ergonomic design is friendly operation and easy maintenance: removable shielding,
auto/semi-auto/manual operation models.
STANDARD PROJECT CASES
1) Metal Jewelry-- JiangSu;(2013)
2) Sumsung Factory- ShanDong; (2013)
3) Faucets --TaiWan (2014)
4) Spoon & Fork & Knife-( Brazil )
5) Car Wheels & Rims -- HeBei ( 2014)
6) Lamp house / lighting cover--ZheJiang(2014)
VAKIA-MSC1250 TECHNIICAL SPECIFICATIONS
| MODEL | VAKIA-MSC1250 | |||||||
| TECHNOLOGY | DC Unbalance Magnetron Sputtering Deposition | |||||||
| MATERIAL | Stainless Steel (S304) | |||||||
| CHAMBER SIZE | Φ1250*1250mm (H) | |||||||
| CHAMBER TYPE | Cylinder, vertical single door | |||||||
| EVAPORTATION SYSTEM |
Either Eight (8) 760mm or Six (6) 700mm planetswith a total length of 1050mm ( approx.) |
|||||||
| DEPOSITION MATERIAL | Silver, Copper, Chrome, Stainless Steel, Aluminum etc. | |||||||
| DEPOSITION SOURCE | Cylinder or Plannar Sputtering Targets | |||||||
| CONTROL | PLC(Programmable Logic Controller) + Touch Screen | |||||||
| PUMP SYSTEM | RotaryPiston Vacuum Pump | |||||||
| Rotary Vane Vacuum Pump | ||||||||
| Roots Vacuum Pump | ||||||||
| Turbo Molecular Pump | ||||||||
| SAFETY SYSTEM | Numerous safety interlocks to protectoperators and equipment |
|||||||
| COOLING | Cold Water | |||||||
| POWER MAX. | 95KW (Approx.) | |||||||
| AVERAGE POWER CONSUMPTION | 40KW (Approx.) | |||||||
| GROSS WEIGHT | 4.1 T (Approx.) | |||||||
| FOOT PRINT | ( L*W*H) 5200*4000*2400MM (Safety Height 4000mm) | |||||||
| POWER ELECTRICAL | 480V/3 phases/60HZ ( USA compliant) 460V/3 phases/50HZ ( Asia compliant) 380V/3 phases/50HZ ( EU-CE compliant) |
|||||||
Please contact us today, Vakia Vacuum Coating is honored to be your your business partner.
