Help CenterCar Plastic Door Handle and Handle Panels Sputtering Coating Machine
Related Products
-
PVD Vacuum Sputtering Coating Equipment on Metals, Ceramic and Glass, MetalsUS$ 5,000 - 80,000MOQ: 1 Set -
PVD Vacuum Sputtering Coating Equipment on Jewelery DecorationUS$ 5,000 - 80,000MOQ: 1 Set
-
Sputtering System PVD Coating MachineUS$ 70,000 - 150,000MOQ: 1 Set
-
Magnetron Sputtering System Coating MachineUS$ 70,000 - 150,000MOQ: 1 Set
-
DC Magnetron Sputtering Coating Machine- 2 Door for ABS Table Ware ApplicationUS$ 5,000 - 80,000MOQ: 1 Set
Thanks for the Magnetron Sputtering Technology which represents a real alternative to
definitively substitute Chrome/Silver/Gold electroplating coating onto metals/ceramics/
resin/plaster/glass and plastic materials which is considered to be a strong pollutant and a health hazard.
The most important is the added value brings to producers. The Sputtering PVD processes
enable almost unlimited production of coatings on any type of complex surface. Mostly, for
aesthetic (decorative), functional coating applications. The metals like: Chrome, stainless steel, aluminum,
Nickel, Silver, Gold, Titanium targets are applied to generate the high quality thin films on consumer goods.
PVD sputtering gives a combination of advantages like no other:
1. It is totally economically efficient generating the thinnest and most uniform coating films;
2. It is a dry coating process at low temperature in a vacuum chamber;
3. It offers great versatility, can be used for the deposition of conductive or non-conductive materials on any type of substrates, like: metals, ceramics, plastic materials.
4. Multi layers coating are available.
Coating Samples:
Vakia-MSC Coating Plants | |||||||
Model |
MSC-800 |
MSC-900 |
MSC-1008 |
MSC-1250 |
MSC-1400 |
MSC-1600 |
|
Chamber Inner size(mm) |
800x800 |
900x900 |
1000x800 |
1250x1250 |
1400x1600 |
1600x1600 |
|
Power Supplies |
Pulsed bias supply, DC power supply, MF power supply, RFmagnetron supply |
||||||
Chamber Type |
Vertical cylindrical model, double doors/single door |
||||||
Chamber Material |
SUS304 |
||||||
Ultimate Vacuum |
6.0×10-4Pa |
||||||
Vacuum Evacuation |
From 1 atmosphere to 8.0×10-3Pa≤10min |
||||||
Vacuum Pump System |
diffusion pump/ molecular pump+ roots pump + mechanical pump + holding pump |
||||||
Sputtering Sources |
Sputtering targets |
||||||
|
Sputtering power supply |
10KW/unit |
20KW/unit |
20KW/unit |
30KW/unit |
40KW/unit |
50KW/unit |
|
Driving System |
planetary driving, central driving |
||||||
Cooling |
Cooling water, with cooling tower or cryopump, Polycold assisted facilities |
||||||
Operation System |
manual / automatic , touch screen , PLC or IPC system |
||||||
Please contact us with your demand specifications, we will get you back within 24 hours.
