Digital wind mppt solar hybrid charge controller
The PV charge controller is a smart device which designed for off-grid PV power system. It has great running performance with LCD display and convenient operation. The controller also automatically control cell cut or connect ordinarily according to the change of battery voltage. The controller makes a full advantage of solar cell resource and also keep battery safe and reliable. The controller is mainly used for independent home PV system, telecommunications base stations, fishermen and herdsmen of electricity, as well as PV power supply in remote mountainous and border. To meet different power station’s need, there are 24V, 48V, 96V, 120V, 192V, 220V, 240V and other normal series voltage level base on different battery voltage of off-grid PV power station system project.
• Intelligent, modularized and simple structure design which make it convenient for maintenance.
• Adopt PWM charging model and multi-stage charge control process.
• With auto protection function of over-charge, electronic short circuit, anti-reverse protection. Prevent the battery group reverse charging to the solar panel array at night.
• Two fans and big heat sink make sure the temperature in good condition.
• LCD screen shows the working status.
• Users can adjust the working parameters according to different solar system.
• Two fans and big heat sink make sure the temperature in good condition.
• With system abnormal status alarm function.
• Self-regulate for voltage drops and temperature effects in solar systems.
• Adopts the industrial-grade chips for all control, which can work under the cold, hot, humid conditions.
• Wall mounting type and easy to fix
| System Capability | ||||||
| Model | SP-P024 | SP-P048 | SP-P96 | SP-P120 | SP-P-240 | SP-P384 |
| PV modules [Vmp] | 30V-43V | 60V-86V | 120V-172V | 150V-216V | 300V-432V | 480V-690V |
| Module arrays input | 1 (standard) / 2(optional) | |||||
| Rated charging current [A] | 30 50 60 75 85 100 120 150 200 | |||||
| Rated battery bank voltage[V] | 24 48 96 120 192 220 240 360 384 | |||||
| Performance | ||||||
| Time delay to cut-off charge | 1 minutes | |||||
| Time delay to charge recovery | 10 minutes | |||||
| Consumption at standby [mA] | <50 | |||||
| Consumption at night [mA] | <20 | |||||
| Topology | Transformerless | |||||
| Operating Temperature Range | -25℃ to +50℃ | |||||
| Cooling Method | Convection with double cooling fans | |||||
| Ambient Humidity | 0%~85% NC25(25(25℃±5 ℃) | |||||
| Altitude [m] | ≤4000 (without power derating) | |||||
| General Data | ||||||
| Terminal | TC series barrier terminal | |||||
| LCD Display | LCD | |||||
| Display Language | English | |||||
| Data communication | RS232/RS485(optional) | |||||
| Ingress Protection Class | IP20 (indoor) | |||||
| Noise [dBA] | <30 | |||||
| Mounting | Wall mounting type | |||||
| Dimensions (W*D*H) [mm] | 395*345*155 | |||||
| Net weight [KG] | 10 | |||||
| Warranty [year] | 3 (standard) / 5(optional) | |||||
