portable and big capacity grain disk mill
Contact Details
Contact Person: Cathy
Skype: Taizy2031
Mobile: 0086-13673685830
How it works ?
When sample (brown rice) from the hopper into white interior run into the ground, because of the pressure in the pressure of thallium and mechanical force, make the brown rice extrusion grinding in white interior and after the friction, and brown rice between grinding wheel and wipe away from each other, which can quickly remove cortex of brown rice, white rice in regulating certain time measured the level of the white degree.
Functions of rice grinder machine
The milling part can process the paddy directly into rice, and separate the rice from bran and broken rice. Grinder part can crush the paddy. corn , sorghum, beans, stem.
Structure composition of rice grinder machine
The machine is consists of four parts: mill machine, grinder machine, motor and shelf. The milling machine is consists of cover, engine base, roller, sieve for rice, feed hopper, slide sieve, belt pulley, actuating device. Grinder machine is consists of feed hopper, shell, exceed hopper.
Advantage of rice grinder machine
1. Portable Home use machine
2. Easy operation
3. Little investment big profit
screen
Parameters of rice grinder machine
Model |
Motor(kw) |
Weight(kg) |
Dimension(mm) |
Capacity(kg) |
9FZ-160 |
3kw |
25 |
350*700*500 |
50-100 |
9FZ-200 |
3kw |
35 |
400*550*550 |
100-150 |
9FZ-280 |
4 kw |
45 |
550*550*400 |
150-250 |
9FZ-300 |
4 kw |
50 |
550*580*400 |
200-300 |
9FZ-300 |
5.5kw |
65 |
850*550*1050 |
300-500 |
9FZ-320 |
7.5kw |
110 |
950*650*1050 |
500-1000 |
9FZ-360 |
11kw |
125 |
1050*750*1150 |
1000-2000 |
9FZ-400 |
18.5kw |
155 |
1250*750*1200 |
1500-3000 |
9FZ-450 |
22kw |
195 |
1350*850*1350 |
2000-5000 |
Notes
1. The machine can not use plug into socket and share with other illuminating line, it must connect the battery main switch and suggest knife switch should be above 10A.
2. Before starting up the machine, please double check the all parts and ensure all fixed not become flexible, then open the cover to check the space of rice roller is correct.
3. When all is ready, please start the switch, and let the machine idling 1-3 minutes. If there is all OK, we can feed the material into machine and begin to process.
