Help CenterSchenck Vertical Balance Machine HV
Related Products
-
Schenck Balancing Machines VIRIOUS$ 1,000 - 100,000MOQ: 1 Pack -
Vertical Balancing Machine, HVUS$ 1,000 - 100,000MOQ: 1 Pack
-
Balancing Machine, HVUS$ 1,000 - 100,000MOQ: 1 Pack
-
Schenck Vertical Dynamic Balancing Machine, HVUS$ 1,000 - 100,000MOQ: 1 Pack
-
Vertica Dynamic Balancing Machine, HVUS$ 1,000 - 100,000MOQ: 1 Pack
Specifications
Vertical balance machineBalancing Machines,HV
Schenck
Balancing in one or two planes possible
Schenck Vertical balance machine,
HV Balancing Machines
Simple operation and minimum floor space requirement
Balancing in one or two planes possible
No time-consuming calibration runs through permanent calibration
Manual basic machine, easily upgraded to a semi or fully automatic machine
Integrated, rotor-adapted protective shroud
Product Specification
Range of application
Measurement and correction of unbalance in disc-shaped rotorswithout their own shaft, in one or two planes. A shorter spindledistance and protective shroud provide faster, safer and more accuratebalancing. Flexible correction units and a variety of accessories caterto many applications manual, semi or fully automatic.
Design
Force-measuring, vertical balancing machine with permanent calibration and manual, semi or fully automatic operation.
Machine housing of mineral-casting, balancing unit designed as adynamometer system with highly sensitive electro-dynamic vibrationsensors, precision balancing spindle and drive motor. Control cabinetwith operating controls and microprocessor-controlled measuring unit.
Protective shroud according to DIN 45690 / ISO 7475.
Correction
Various correction units permit integration of mass correction inthe balancing machine at almost any correction position. Thus axial orradial correction can be controlled manually, semi or fullyautomatically. Various methods of material removal as well asattachment of correction weights (material addition) are possible. Thisenables the machine to be used universally for a large variety ofrotors.
| Product parameters | ||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||||||
