Place of Origin Shanghai, China
Brand Name Schenck
Model Number 450SHV
Power Electronic
Usage Vibration Testing Machine

Specifications

Automatic Balancing Machine ,dynamic balancing machine
Schenck 450SHV Balancing Machine

Automatic Balancing Machine

Schenck 450SHV Balancing Machine



Range of application

The machine is designed for the automatic balancing of disc-shaped parts in one plane.

Automatic balancing machine 450SHV with one station is one of the advanced vertical balancing
machines of Schenck Rotec GmbH. The machine integrates the advanced Schenck Germany's
technology, and key components import form Schenck Germany. The whole balancing task is
completed automatically including measuring, indexing, milling correction and checking. 450SHV
is a good choice to mass produce with short cycle time, high efficiency and high accuracy.
CAB759 is the advanced measuring unit of Schenck Germany integrating measuring function,
control and calculating function together. It comprises the measuring unit and industrial PC with
LCD touch screen, friendly interface and powerful functions.

Sequence of operations

load the workpiece manually
automatically measuring,milling correction and checking
protection door open automatically
unload the workpiece manually


Product parameters

Technical Data


450SHV

Data of rotors

Max. Weight of rotors

kg

30

 Diameter of rotors

mm

400

Machine data

R&R

%

10

Average cycle time without
loading and unloading
(milling angle 30)

Approx.s

35

Balancing speed

1/ min

100

Driving power

Kw

3

Unbalance correction

Cutter diameter

mm

125

Milling width (depending on the rotors)

mm

6/25

Milling depth (depending on the rotors)

Approx.mm

3

Milling angle (depending on the rotors)



75

Milling spindle speed

Approx.rpm

900

Driving power

Kw

7.5
