Home > Instruments & Meters > Test Instrument > Test Machine > Dynamic Balancing Machine RBTU

Dynamic Balancing Machine RBTU

Name: Dynamic Balancing Machine RBTU
Brand: Schenck
SKU: 122668057

Dynamic Balancing Machine RBTU thumbnail-1

US$ 100,000 - 1,000,000 MOQ: 1 Pack

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Schenck

Model Number:

RBTU

Contact Supplier Request Quote Chat Now

Schenck Shanghai Machinery Corp., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name Schenck

Model Number RBTU

Power Electronic

Usage Vibration Testing Machine

Specifications

Automatic Balancing Machine Type RBTU
Schenck RBTU Balaning Machine

Automatic Balancing Machine Type RBTU

German original measuring unit base on Windows XP operation system and human-machine interaction

Application

The balancing machine is designed for measuring and correction theunbalance of various kind of armatures. Be able to connect armatureproduction lines to attain a high production rate.

unbalance correction by slot milling, polar profile milling or drilling.

Correction Procedure

Polar Profile Milling

The unbalance is corrected in the measured angular position regardless to the slot division.

Slot Milling in Components

In accordance to the number of pole heads the measured unbalance issplit into components and corrected by slot milling into the pole headsof the rotor stack.

Drilling

Correct the unbalance by drilling into the lamination or pole claws.

Product parameters

	weight	Max. kg	1.5	Depending on weight and shaft diameter either prism or roller bearing are used in the measuring station.
	Shaft length	Max. mm	230
	Shaft diameter	Max. mm	12
	Stack height	Max. mm	70
	Stack diameter	Max. mm	80
Cycle Time	17s
