Specifications
Balancing Machine TypeSchenck Automatic Machine
Digital measurement and control
German original measuring unit
Balancing Machine Type RBTU, Schenck Automatic Machine
German original measuring unit base on Windows XP operation system and human-machine interaction
German rich mechanical design and manufacture experience
Digital measurement and control
Software system can be recovered by backup conveni-nently
Be capable to connect armature production line
Support remote control and maintenance
Product Specification
Application
The balancing machine is designed for measuring and correction theunbalance of various kind of armatures. Be able to connect armatureproduction lines to attain a high production rate.
Unbalance correction by slot milling, polar profile milling or drilling.
Correction Procedure
Polar Profile Milling
The unbalance is corrected in the measured angular position regardless to the slot division.
Slot Milling in Components
In accordance to the number of pole heads the measured unbalance issplit into components and corrected by slot milling into the pole headsof the rotor stack.
Drilling
Correct the unbalance by drilling into the lamination or pole claws
| Product parameters | |||||||||||||||||||||||
Above technical data will be amended because of improving balancing machines. | |||||||||||||||||||||||
