Free Software Car Gps Tracker Tk103-2

Free Software Car Gps Tracker Tk103-2 thumbnail-1
Free Software Car Gps Tracker Tk103-2 photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Tracker
Use:
Automotive
Screen Size:
Other
Contact Supplier Request Quote Chat Now
Shenzhen Boshijie Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Tracker
Use Automotive
Screen Size Other
Function Other
Place of Origin Guangdong, China
Brand Name BSJ
Model Number BSJ-A08

Specifications

Shenzhen Auto GPS Tracking Device A-08
1.Feature: Tracking, Anti-thief, Alarm
2.Size:76mm*66mm*43mm
3.GPS accuracy:10m

Specifications

Shenzhen Auto GPS Tracking Device A-08
1.Feature: Tracking, Anti-thief, Alarm
2.Size:76mm*66mm*43mm
3.GPS accuracy:10m

Shenzhen Auto GPS Tracking Device A-08

Detail:

1. Real-time GPS tracking

2. Real-time vehicle status monitoring

3. Vehicle Immobilization Control

4. GPS mileage report

5. Blind area data storage, up to 50,000 data log capacity

6. Geo-Fence with 108 rectangle area

7. Fleet management, 4 routes of vehicle tracking

8. Anti-theft and emergency alarm

9. Remote listen-in, hand-free telephone (Optional speaker)

10. Overspeed alerts

11. Smart power protection

12. Remote firmware upgrade via GPRS

13. Dual data communication capability through GPRS

14. TCP/UDP dual mode communication



free software car gps tracker tk103-2





GSM/GPS module performance

Dual-Band 900Mhz,1800Mhz(850/1900MHz optional)

2 watts EGSM(GSM900 class 4)

1 watts GSM1800(DCS1800 class 1)

GPRS class 10

GPS Chipset

Latest U-blox 5M high sensitivity chipset

GPS Sensitivity

-159dB

Channels

20/50 channel all-in-view tracking

Dimension

76x66x43mm

Weight

150g

Working Voltage

DC 9V~36V

Normal power consumption

80mA (Power Saving Mode<20mA)

Working Temperature

-20°C~+70°C

Working Humidity

5%~95% RH

Antenna

1. GPS 2. GSM

Interface

1.4 Digital Inputs (3 Positive Triggers & 1 Negative Triggers).

2.1 relay output 250mA 12VDC.

3.1 RS232 interface.

Application

1. Taxi dispatch management.
2. Long distance passage vehicle GPS monitoring.
3. Bus GPS scheduling management system.
4. Logistics vehicle GPS monitoring and management system.
5. Rental vehicle GPS monitoring system.
6. Extended LED screen for advertising purpose.
7. Extended LCD screen for dispatching.







 free software car gps tracker tk103-2

- TheBSJ-A08 GPS, GSM Tracker is a vehicle remote position device with build-in GPS and GSM, GPRS modules. It is a small size, high accuracy remote location tracking device. Based on GPS satellite, it provides accurate position information under dynamic conditions. Personal remote position device transmit the longitude and latitude coordinate to authorized cell phone.
- GPS, GSM vehicle tracker mainly uses for motorcycle, electric golf cars, and ordinary car. The device has built in antenna, integrative machine and easy to assemble.
- You can use these features for a security purpose and other purpose which needs remote positioning such as asset protection and tracking.
- Support GSM  850,900,1800,1900MHz
- High sensitivity, U-BLOX low power GPS chipset
- Excellent for fixing the position even at a weak signal status, work well even in areas with limited sky view like urban canyons,when you drive into blind area,the terminal still can uplaod replenish driving data.
- Fast Signal Acquisition
- Support single location and continuous tracking
- Support alarm

- Support check location and real-time and historical trajectory by  Internet
- SOS button send out exact location for immediate rescue, action.
- High reliability circuit design, in line with the automotive electronics industry standards
- Specifications:
- GSM module:ARM program, GSM 850, 900, 1800, 1900MHz optional) Quad-bands;

  •   Support the TCP/UDP protocol
    - GPS Chipset: U-BLOX chipset
    - GPS Sensitivity: -159dBm
    - GPS Frequency: L1, 1575.42MHz
    - C, A Code: 1.023MHz chip rate
    - Channels: 16 channel all-in-view tracking
    - Position Accuracy: 10 meters, 2D RMS
    - Velocity Accuracy: 0.1 m, s
    - Time Accuracy: 1 us synchronized to GPS time
    - Datum: WGS-84
    - Reacquisition: 0.1 sec., average
    - Hot start: 1 sec., average
    - Warm start: 38sec., average
    - Cold start: 45sec., average
    - Altitude Limit: 18,000 meters (60,000feet) max.
    - Velocity Limit: 515 meters, second (1000knots) max.
    - Acceleration Limit: Less than 4g
    - Jerk Limit: 20m, sec
    - Operating temperature: -20 to +70 (Celsius)
    - Humidity: 5% to 95% Non-condensing
    - Voltage: 12V
    - Average Current when stand-by: <80mA
  • - LED Green, Blue, Red LED showing GPSGSM and power status
    - Out set SOS Key
    - One SOS emergency key: for urgent call
    - Components:
    - Build-in GPS+GSM module with integrated antenna
    - 3.7V 650mAh rechargeable battery x1

free software car gps tracker tk103-2





free software car gps tracker tk103-2







Company:



free software car gps tracker tk103-2



free software car gps tracker tk103-2





Certificates:



free software car gps tracker tk103-2free software car gps tracker tk103-2
