cheap mini gps tracker work on wide voltage DC 9V - DC 90V vehilces
MINI-W device is a very mini size gps tracker. Voltage of this device is wide, from DC 9V ~ 90V. You can use it on motorcycle , car, truck, electromble, for real time monitoring.
MINI-W comes with 4 wirs, 2 wirs for power, 1 wire for relay, one is reserve. When conenct relay, u can remote shut off enigine.
And it supports over-speed alarm, GEO-Fence alarm, main power off alarm ect.
Application:
mVehicle Real time Tracking
mcar & motorcycle & fleet management
Functions:
| Basic function | vehicle real time tracking (roll call / timing tracking) |
| vehicle statue detected (ACC on /off detected; vehicle moving detected) | |
| remotely engine cut off | |
| GEO-Fence | |
| blind area data upload | |
| mileage statistics | |
| OTA | |
| Alarm function | Speeding / over-speed alarm |
| low power alarm | |
| main power off alarm | |
| moving alarm | |
| Blackout&car burglar alarm | |
| Others | AGPS |
| Low power consumption |
Specification:
| Item | Parameter |
| Working voltage | DC9V ~ 90V |
| Working current | 35mAH @ 12V |
| Dimention | L52*W42*H15mm |
| Position mode | GPS / AGPS |
| Position error | <10m |
| Communication network | GPRS |
| Communication mode | TCP |
| GPS sensitivity | -159db |
| GSM frequency band | GSM 850/900/1800/1900MHz |
| Memory | 128KB flash |
| Working temperature | -25℃~75℃ |
| Humidity | -40℃~85℃ |
| Blackup battery | 1.5hours for sleeping mode; 45mins for working mode |
Details:
Tracking platform:
Web based tracking platform
APP for Android cell phone
Why choose BSJ
Q: How many customers BSJ have now?
A: More than 100000 overseas users are using BSJ tracking systems, mainly from South America, Africa, Southeast Asia and Eastern Europe. we are top 3 in tracking systems area in China
---------------------------------------------------------------------------------------------------------
Q: How long to delivery order?
A: Ship goods in 1-3 working days by DHL with competitive shipping cost, only need 3-5 working days to get at every corner of the world.
---------------------------------------------------------------------------------------------------------
Q: How about BSJ after-service?
A: BSJ have a professional sales team to provide with you professional and considerate support, if needed, we can guide you operate GPS tracker and live GTS software online by MSN/Skype/Yahoo/G-Talk step by step .
--------------------------------------------------------------------------------------------------------
Q: Does BSJ have ability tog modify device and software to meet our special needs?
A: Yes, sure. BSJ have professional engineers team to develop GPS tracker device and livegts tracking software to meet almost user’s need .
--------------------------------------------------------------------------------------------------------
Q: Any discount any preferential for the first cooperation.
A: Of course
Firmware
| 1.Boshijie firmware and software programming is configured by our in house team of engineers |
| 2.This team is qualified to develop new firmware for customer’s protocol or for newly added functions |
| 3.Boshijie welcomes customer inquiries and challenges for our team of engineers |
|
4.Firmware development includes but not limited to :New firmware (different protocol) development ; Modification to current firmware New function development |
Hardware
| 1. Backed by an R&D team of over 50 engineers, develop new hardware according to customer’s requirements as well as further modifications based on our existing products. |
|
2.Hardware design includes but not limited to: PCB Re-layout New case design External Device Integration |
