NEW DODO-HM Aerosol Can Maker
New DODO-HM is specially designed to manufacture aerosol tinplate can body with functions of rolling,welding,coating.With performances of high output,constant and stable welding quality,easy operation,solid and good-looking weld seam,suit various can sizes,it is the best canning equipments.
Main Feature:
1.Equipped with human-computer-interface.
2.Adopt digital control technology.
3.New digital inverter for power supply.
4.Main drive and copper wire adopt inverter for speed regulation.
5.DODO-S welding system.
| Type | QL-2612-HM |
| Welding speed | 7-26m/min. |
| Welding point distance | 0.5-0.9mm |
| production capacity | 120cans/min. |
| Overlap | 0.4mm |
| Can diameter | 52-99mm |
| Can height | 70-320mm |
| sheet thickness | 0.16-0.36mm |
| Material | Tinplate, Ni plate |
| Tin coating | Tin:#5-#100 |
| Temper | T2.5-DR8 |
| Copper wire | diameter: 1.38mm, 1.5mm |
| Power | three phase, voltage:380V |
| welding frequency | 120-260Hz |
| Cooling water | 392-490kpa, 12-18°c, 20L/min. |
| Compressed air | 490kpa, 800L/min. |
| Dimensions | 2280 X 2020 X 2060mm |
