Specifications
Precision Fiber Optic Strippers of various types with precise tolerances.Precision Fiber Optic Strippers CFS-2
• For stripping 250 micron buffer coating to expose 125 micron cladded fiber
• Second hole for stripping 2-3mm fiber jackets
• 140 μm diameter hole and V-opening in blade allows removal of 250 micron buffer coating from 125 micron fiber
• Pre-set at the factory – no adjustments needed
• Will not scratch or nick glass fiber
• All stripping surfaces are manufactured to precise tolerances to assure clean, smooth strips
• Comfort-grip, ergonomic handles
• Lock to hold tool closed when it is not in use
Fiber Optic Stripper FO 103-S
• For stripping 250 micron buffer coating from 125 micron optical fiber
• Precision diameter hole & V-opening in blade allow for accurate buffer coating removal
• Factory set, requires no adjustment
• Prevents scratching or nicking of optical fiber
• All cutting surfaces are precision formed, hardened, tempered and ground assuring precise buffer removal
• Length:136.5mm, Weight: 71g
Fiber Optic Stripper FO 103-S
• For stripping 250 micron buffer coating from 125 micron optical fiber
• Precision diameter hole & V-opening in blade allow for accurate buffer coating removal
• Factory set, requires no adjustment
• Prevents scratching or nicking of optical fiber
• All cutting surfaces are precision formed, hardened, tempered and ground assuring precise buffer removal
• Length:136.5mm, Weight: 71g
Multi-function fiber optic stripper
• Fiber Stripper, 2.0mm-3.0mm Outer Jacket, 900/125um & 250/125um Fiber
•The new multi-function fiber optic stripper provides you with five settings for stripping fiber optic cable. This fiber optic stripper enables you to remove the outer jackets from 2.0-2.4mm fiber, 2.8-3.0mm fiber and 2.0-3.0mm loose tube buffer tubes.
•Also use this fiber optic stripping tool to remove buffer and acrylate from 900/125μm and 250/125μm fiber.
•Factory set and calibrated, ensuring precise strips.
Tri-Hole Fiber Optic Stripper FO103-T-250-J
• New three-hole model performs all common fiber stripping functions in one compact tool.
• Standard 250 to 125 micron stripping
• Remove 900 tight buffer to 250 micron buffer coating
• Hole for removal of 2 to 3 mm fiber jackets
• Same consistent quality and features found in our standard FO 103-S tool
Dual-Hole Fiber Optic Stripper
Part |
Description |
FO103-D-250 |
stripper for removal of 250μm buffer coating from 125μm optical fiber. The second hole strips 900μm tight buffer down to a 250μm buffer coating |
FO103-D-J |
used for 250μm buffer coating removal from 125μm fiber. The second hole strips 2- to 3-mm fiber jacket |
No-Nik® Fiber Optic Stripper
•Exclusive centering device positions fiber for precise scoring and removal of buffer coating, Razor-sharp blades score buffer without cutting through it, Color-coded, cushion-grip handles for quick identification, Stripping blade diameter clearly market on plastic head.
|
Model
|
Handle Color |
Min. Stripping Diameter |
NN152 |
Gold |
152um .006in |
NN175 |
Mustard |
175um .007in |
NN203 |
Red |
203um .008in |
NN254 |
Lt. Blue |
254um .010in |
NN305 |
White |
305um .012in |
Micro-Strip® Fiber Optic Stripper
|
Model
|
Handle Color |
Min. Stripping Diameter |
NN152 |
Gold |
152um .006in |
NN175 |
Mustard |
175um .007in |
NN203 |
Red |
203um .008in |
NN254 |
Lt. Blue |
254um .010in |
NN305 |
White |
305um .012in |
