Specifications
Epoxy Curing Equipments HW-1024, HW-1064, HW-1050 for curing the epoxy of fiber connectors.Fiber Optic Epoxy Curing Oven HW-1024
• 24 Port Epoxy Curing Oven provides cure for several types of epoxy and the oven block accommodates a variety of Optical Fiber connector types including ST, FC, SC, D4 and SMA. Block provides even heat distribution, minimizing connector heat loss. Temperature range is ambient to 320° F/160° C. Optional holding block accommodates MU and LC connectors. Oven requires only a standard plug outlet.
• Temperature Control and “Power On” Indicator
• Includes 24 Port Block for FC, ST, SC, SMA, D4 Connectors
•Specifications include: 110 V, 120 V ac, 1.1 A, 132 W, 50/60 Hz and 1.5 fuse A
• Easy to Use – A Favorite of Many Installers
• Available in AC 110V or AC 220V
64 Port Fiber Optic Epoxy Curing Oven HW-1064
Features:
• Specially designed for curing the epoxy of fiber connectors.
• 64 connectors can be cured simultaneously.
• Suitable for different connectors via interchangeable heating blocks for increased flexibility and lower cost.
• Alarm reminds operator when curing cycle completes.
• Overheat protection at 199 Degrees Centigrade
• Heat resistant acrylic shelf separates heating block from controls.
• Machine Size Width 310mm (12.2in) Length 220mm (8.66in) Height 160mm (6.3in)
96 Port Connector Heat Oven HW-1050
• HW-1050 fiber connector heat oven are dedicated to heating Ceramic Ferrule 96 port and heating connector 48 port
• Applications: Multimode and Single mode
• Temperature control(0°C-300°C) and “Power On” indicator
• Temperature Stability: +/- 3°C
• Time to read 300°C: ~8 minutes
• Available in AC110V or AC220V
• Easy to Use – A Favorite of Many Installers
