Factory Direct High Quality Two Roll Rubber Open Mixing Mill XK-560 Two Roll Mill for Rubber

Name: Factory Direct High Quality Two Roll Rubber Open Mixing Mill XK-560 Two Roll Mill for Rubber
Brand: QDHC
SKU: 122636589

US$ 6,000 - 50,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, Open Mixing Mill, Rubber Mill

Place of Origin:

Shandong, China

Qingdao Huachuan Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Open Mixing Mill, Rubber Mill

Place of Origin Shandong, China

Brand Name QDHC

Model Number XK

Voltage 220v/380v/440v

Power(W) According to the different size

Dimension(L*W*H) According to the different size

Weight According to the different size

Certification CE ISO

Warranty one year

After-sales Service Provided Overseas service center available

Factory Direct High Quality Two Roll Rubber Open Mixing Mill XK-560 Two Roll Mill for Rubber

Our company introduce

We are QINGDAO HUACHUAN MACHINERY CO., LTD. Located in the machinery manufacture base of

QINGDAO Seaport (top 10 of world),develop for over 30 years of experience of R&D and sales, pass of ISO 9000

managment system & CE quality certification. As one of the leading machinery manufacturers such as: Shot/Sand blasting

machine (polish the steel surface rust, strength the steel qulity suit for steel plate, road surface, H beam, outer/inside pipe,

oil pipeline casting etc);

Technical parameters

model		XK-150	XK-250	XK-300	XK-360	X(S)K-400A	X(S)K-450A	X(S)K-560A
Working diameter rolle(mm)		φ150	φ250	φ300	φ360	φ400	φ450	φ560
The length of roller work(mm)		320	620	750	900	1000	1200	1530
Front roller speed(m/min)		11.24	14.4	15.1	16.25	18.65	24.5	29.09
Before and after the roller speed ratio(m/min)		1:1.4	1:1.17	1:1.27	1:1.25	1:1.27	1:1.27	1:12
Roll away the largest(mm)		8	8	8	10	10	15	20
A feeding quantity(kw)		1-2	10-15	15-20	20-25	18-35	25-50	50-65
Driving motor power		1.5	18.5	22	30	37	55	90
outline demension (mm)	length	1080	3400	3580	3780	4250	5200	6120
	width	796	1500	1550	1850	1850	2380	2282
	height	1415	1500	1695	1740	1870	1770	2000
weight(kg)		1100	3500	5200	6500	7600	13000	22000
