Specifications
1.Resistance to burning hot metal ladle.2.Multi-purpose hot metal ladle.
3.Safe and reliable design.
4.Easy operation.
cast steel slag ladle
Hot metal ladle for foundry casting operation,after undertaking iron liquid in front of the furnace , send it to the casting model place to pour by driving car.
We provide the TB manual, electric hot metal ladle,the following is their technical parameters:
Specification |
Up diameter Φ1(mm) |
down diameter Φ2(mm) |
Bucket height H(mm) |
Width A(mm) |
Height B(mm) |
TB-0.3 |
Φ520 |
Φ470 |
540 |
1070 |
1310 |
TB-0.5 |
Φ606 |
Φ546 |
590 |
1136 |
1349 |
TB-0.75 |
Φ643 |
Φ583 |
665 |
1207 |
1456 |
TB-1 |
Φ722 |
Φ652 |
740 |
1260 |
1479 |
TB-1.5 |
Φ830 |
Φ750 |
860 |
1380 |
1856 |
TB-2 |
Φ897 |
Φ810 |
910 |
1437 |
1890 |
TB-2.5 |
Φ943 |
Φ853 |
960 |
1550 |
2057 |
TB-3 |
Φ1020 |
Φ920 |
1035 |
1621 |
2131 |
TB-3.5 |
Φ1045 |
Φ945 |
1070 |
1634 |
2157 |
TB-4 |
Φ1132 |
Φ1020 |
1145 |
1719 |
2183 |
TB-5 |
Φ1230 |
Φ1110 |
1248 |
1887 |
2525 |
TB-7 |
Φ1368 |
Φ1238 |
1337 |
2030 |
2678 |
TB-8 |
Φ1418 |
Φ1278 |
1428 |
2402 |
2960 |
TB-10 |
Φ1542 |
Φ1402 |
1592 |
2525 |
3095 |
TB-12 |
Φ1640 |
Φ1480 |
1652 |
2700 |
3283 |
TB-15 |
Φ1765 |
Φ1586 |
1785 |
2815 |
3540 |
TB-20 |
Φ1930 |
Φ1736 |
1973 |
3010 |
3870 |
TB-25 |
Φ2090 |
Φ1878 |
2131 |
3420 |
4050 |
TB-30 |
Φ2245 |
Φ2015 |
2296 |
3780 |
4200 |
TB-40 |
Φ2540 |
Φ2315 |
2675 |
4090 |
5225 |
TB-45 |
Φ2665 |
Φ2395 |
2740 |
4350 |
5340 |
TB-50 |
Φ2756 |
Φ2467 |
2895 |
4600 |
|
Execution standard JB/T5771-2006
