I. General | |
Power supply |
3 phase / 380V/50HZ |
Processing raw material/ resin |
HIPS and PP virgin or recycled granules |
Sheet thickness range |
0.3-2mm |
Application |
Thermoforming sheet |
|
Sheet multi-layer structure (Co-extrusion) |
B, A-B or A-B-A, A-B-C-B-A exchangeable; |
Extrusion output (max) |
900kgs/hr |
Line speed |
2.5-25M/Min (depending on sheet thickness) |
II. Standard device | |
Raw material processing system |
1set |
JBD120/33 single screw extruder |
1set |
JBD65/33 single screw extruder |
2setS |
Hydraulic screen changer |
3sets |
Melt pump |
3sets |
Feedblock |
1set |
T-Die |
1set |
Three roll calendar L type |
1set |
Roll temperature controller |
1set |
Cooling roller conveyor (with edge trimming unit) |
1set |
Winder for edge trimming |
1set |
Take off unit |
1set |
Electricity eliminator |
1set |
Revolving type winder |
1set |
Electric control system |
1complete set |
Welcome to visit our factory!
