PET Plastic sheet extrusion machine, energy saving, high output, for producing high quality PET thermoforming products for packaging purpose, standard output approx 500kgs/hr, our standard sheet width is 710mm, sheet thickness range 0.2-2mm.
PET is used widely in plastic processing field because it has good transparent, neutral in taste, high impact resistance, easy recyclability and other excellent properties.
Basic Parameter:
Sheet Thickness Range: 0.2-2mm
Range of Finished Width: 500-1800mm ( wider on Request )
Processed Polymers: APET, PETG and Special Coex structures, EVOH and PE.
Line configuration:
Raw material handling:
Feed System: Individual Auto-vacuum Loaders
Material Drying: Individual Designed
Volumetric or gravimetric dosing: Up to 4 Components Per Extruder
Extrusion System:
Type of Extruder: Single Screw or Twin Screw Extruders
Size of Extruder: Single Screw 65, 90, 120, 150
Twin Screw 52, 65, 75, 95
Melt Pump: Standard for PET
Flat T-dieManual or Automatic Die,Cloth-hanger flow-channel
Downstream:
Calendering type: Inclined or Horizontal Type
Calendering rollers: 320mm,450mm,600mm
Roller temperature control: Chiller and water thermoregulators
Edge trimming and recycling:
Trimming type: With Blades or Motor Driven circular Knives
Grinder: Inline grinding and refeeding directly
Take off Unit:
Roll Size of take-off: 200mm,250mm
Rubber and Steel rollers
Winder system
Winder type: Jumbo roll winders(electric drives)
Turret winders
Normal winder
Fully automatic winders
Automation: JOBBETTER PLC control system equipped with famous electrical parts in the world.
