Specifications
Tyre steel bead wire coated by copper1.From 0.78mm to 2.10mm
2.Coated by copper
3.Approved by the CNACL
4.ISO9001:14001
Tyre steel bead wire coated by copper
Introduction:
Our main products include steel wires of semi-steel,all-steel tempering bead wire with the diameter from 0.78mm to 2.10mm, and series of mining steel wire ropes. we are the largest steel wire production base in Shandong Province. This company have abundantly experience in administration , advanced technology equipment, perfect rational testing measurement and strict process control,Its properties products have been proved by the CNACL tests to reach or surpass the national standard, which has been passed the authentication of ISO9001 International Quality Management System and the ISO14001 Environment Management System. The company owns the most advanced equipments, such as the straight line wire drawing machine, the open-fire heat treatment product line and the continuous product line using heavy H-Wheel wire-rewinding machine. This company is proud of excellent equipments, advanced technology, perfect rational testing measurement and reliable and stable products quality. Currently, the products are sold hundreds of enterprises of domestic and America, Korea,Thailand,Vietnam, Philippines, India, Sri Lanka, Cuba.
Specification
Items |
0.89MM |
0.95MM |
0.96MM |
1.00MM |
1.20MM |
1.65MM |
Diameter mm |
0.89± 0.02 |
0.95± 0.02 |
0.96± 0.02 |
1.00± 0.02 |
1.20± 0.02 |
1.65± 0.02 |
Elongation % ≥ |
5 |
5 |
5 |
5 |
5 |
5 |
Torsion Turns/L=100D ≥ |
28 |
28 |
28 |
28 |
28 |
28 |
Straightness mm/3m ≤ |
500 |
500 |
500 |
500 |
500 |
500 |
Adhesion force N ≥ |
950 |
950 |
950 |
950 |
960 |
1000 |
Tensile strength Mpa ≥ |
1900 |
1900 |
1900 |
1850 |
1900 |
1900 |
Copper % ≥ |
97 |
97 |
97 |
97 |
97 |
97 |
Tin % ≤ |
3 |
3 |
3 |
3 |
3 |
3 |
Plating thickness μm |
0.08-0.15 |
0.08-0.15 |
0.08-0.15 |
0.08-015 |
0.08-0.15 |
0.08-0.15 |
Package
1. Every coil was wrapped by the dampproof paper and reinforced evenly with six steel bands.
2. Put three coils bead wire on one pallet which has been underlaid a coat of lincrusta, there is a coat of dampproof paper between every two coil, at the same time, put the bead wire into a plastic bag and following into the desiccant.
3. The plastic bag was vacuumized and sealed.
4. The outside package was pvc reel and covered a sheet of dampproof paper on the up bottom, then fixing the whole package with steel bands.
5. There are three coils bead wire on one pallet, the weight of one coil is about 400KGS.One container can be loaded 21-24 pallets, the total weight is about 20-25T(this is up to the container room or the shiping agent’s request).
