PE Film Blowing Machine With Single Manual Winder
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polythene Plastic Film Blowing MachineNegotiableMOQ: 1 Set -
Newest Double Winders Plastic pe Film Blowing MachineNegotiableMOQ: 1 Set
-
Double Winders Plastic PE Film Blown MachineNegotiableMOQ: 1 Set
-
LLDPE/LDPE/HDPE Film Blowing Machine/Plastic Blowing Machine With Double WindersNegotiableMOQ: 1 Set
-
Latest pe Plastic Film Blowing MachineNegotiableMOQ: 1 Set
Condition
New
Application
Film
Plastic Processed
PE
Blow Moulding Type
Extrusion Blow Moulding
Automatic
No
Place of Origin
Fujian, China
Brand Name
Donghailong
Model Number
SJ65-FMS1300P
Voltage
220/380V
Power(W)
~62kw
Dimension(L*W*H)
6.3*3.0*5.0m
Weight
~4200kg
Certification
CE,TUV,SGS
Warranty
1 YEAR, 1 Year
After-sales Service Provided
Engineers available to service machinery overseas
LDPE/LLDPE/HDPE film blowing/blown machine&plastic film extruder plant
- SJ65-FMS1300P Blown Film Machine for the manufacture of PE Film consisting single screw extruder with main motor variable speed drive, hopper, barrel, screw, cross head and dies, bubble calibrating & stabilizing basket, control cabinet with temperature controllers, air cooling rings with blowers, vertical take off unit, nip rollers, wooden flattening boards for bubble guides complete with electricals and drives as per following specifications.
1*)Model no.: SJ65-FMS1300P
Layer Number: Single Layer
Max.Film Width: 1250mm(LD) 1200mm(HD)
Film Thickness: 0.020~0.18mm(LD) 0.015~0.12mm(HD)
Output: 100kg/h
Raw Material: HDPE/LDPE/LLDPE
2*)Extruder
Screw diameter: Φ65mm
Screw L/D:28:1
Heater Capacity:13.2kw
Driving Motor:30kw
3*)Die (Option One)
Die diameter:LDPE:Φ300MM HDPE:Φ80mm,Φ110mm
Heater Capacity:LD 6.7kw HD 6.1kw
Cooling Air Blower:4kw
4*)Haul-off
Driving Motor:1.5kw
Take-up speed:10-70m/min
Winder Drive Motor:4kw
Tempreture control: 4kw
Machine power:~62kw
Shape size:6.3*3.0*5.0m
Weight:~4.2t
