Double Lines PE Plastic Film Extruder &Film Blowing/Blown Machine/ pp extruder
1) This film extuder is designed to produce plastic film made of low density polyethylene (LDPE), high density polyethylene (HDPE), linear low density polyethylene (LLDPE).
2) The extruder is specially designed to produce products with small size, which can improve the production efficiency. It is the ideal choice for the traders.
3) With high output, low energy consumption, good stability and reliability.
4) The products are widely used in application of package of civil and industrial products such as food, garment, textile and daily necessities etc. It includes vest bag, shopping bag, garment bag and food bag.
|
MODEL NO.
|
SJ55-2FMS500DL |
SJ65-2FMS650DL |
|||||
|
LAYER NUMBER
|
1 |
||||||
|
MAX. FILM WIDTH
|
mm |
2 X400 |
2 X 600 |
||||
FILM THICKNESS |
mm |
0.008~0.15 |
|||||
OUTPUT |
Kg/h |
40 |
50 |
||||
RAW MATERIAL |
LDPELLDPEHDPE |
||||||
EXTRUDER | |||||||
SCREW DIAMETER |
mm
|
Φ55 |
Φ65 |
||||
SCREW L/D |
28:1 |
||||||
HEATER CAPACITY |
kw |
10.7 |
16.5 |
||||
DRIVING MOTOR |
kw |
18.5 |
30 |
||||
DIE (Rotating die is optional) | |||||||
|
DIE DIAMETER (LD & HD free choice) |
mm |
LDPEΦ100 X 2 |
LDPEΦ150 X 2 |
||||
HDPE Φ30 ,Φ50 X 2 |
HDPE Φ50 ,Φ70 X 2 |
||||||
HEATER CAPACITY |
kw |
LDPE:3.45 X 2 |
LDPE:4.0 X 2 |
||||
HDPE:3.45 X 2 |
HDPE:3.45 X 2 |
||||||
|
|
||||||
HAUL-OFF | |||||||
DRIVING MOTOR |
kw |
2 X 1.5
|
|||||
TAKE-UP SPEED |
m/min |
10~55 |
|||||
WINDER DRIVE MOTOR |
kw |
3.3 X 2 |
4 X 2 |
||||
TEMPERATURE CONTROL |
point |
8 |
|||||
WHOLE POWER WITH TOTAL MACHINE |
Kw
|
~48 |
~67 |
||||
SHAPE SIZE |
m |
4.5 X 4.0 X 3.8 |
5.0X 4.5X 4.0 |
||||
WEIGHT |
t |
~ 2.8 |
~ 3.5 |
||||
Correct specifications depend on the actual model all specifications are subject to change without prior notice | |||||||
