Embossed Film Line pet film extrusion line
Features:
This line mainly uses LLDPE,LDPE,HDPE and EVA as raw materials produce embossed film.The film is suitable for home,medical treatment,garments,industry and public.It is an ideal environment protection product that could replace PVC plastic products.
Main technical parameters:
Model |
TSJ-1500L |
TSJ-2000L |
TSJ-2500L |
TSJ-3500L |
Screw Diameter |
Φ90mm |
Φ110mm |
Φ125mm |
Φ150mm |
L/D Ratio Of Screw |
35:1 |
35:1 |
35:1 |
35:1 |
Width Of Die Head |
1500mm |
2000mm |
2500mm |
3500mm |
Width of Finished Products |
1200mm |
1700mm |
2200mm |
3200mm |
Thickness of Finished products |
0.02-0.20mm |
0.02 -0.20mm |
0.02-0.20mm |
0.02-0.20mm |
Max Extrusion Capacity |
150kg/h |
200kg/h |
240kg/h |
320kg/h |
Total Power |
120kw |
165kw |
210kw |
260kw |
Overall Dimension |
13x4.5x4.0m |
14x5.5x4.0m |
15x6.0x4.2m |
17x7.5x4.3m |
Weight |
~20t |
~27t |
~32t |
~32t |
PS:Correct specifications depend on the actual model all specifications are subject to change without prior notice.
